Fiber Optic Power Meter/Optical Power Detector
- 100000 Piece / Pieces per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | HYG | Model Number: | HYG-099 |
Packaging Details
International Standard Package
Product Description
Specifications
Optical Power Meter, Optical Power Detector1.Data storage & software
2.multi-connectors
3.wide test range
4.Support OEM
Fiber Optic Power Meter/Optical Power Detector
² Self-calibration function.
² High performance import laser detector.
² High sensitivity and large dynamic range
² 0.01 dBm precision
² Automatically converted Range
² Small size, light weight, high reliability
² Battery-powered, convenient field work
² Line display or relative loss displayed.
[Specifications]
Type | HYG-099 | HYG-099 |
Detector | InGaAs | Fitered InGaAs |
Wavelength Range(nm) | 850,1300,1310,1490,1550,1625 | 850,1300,1310,1490,1550,1625 |
Power Measurement range(dBm) | +6 ~ -70 | +26 ~ -50 |
Uncertainty | +5% | |
Resolution Ratio | 0.01dBm | |
Power Supply | 2 AA1.5V Batteries or (Chargable battery) | |
Optical Connector | FC-type adapter (SC,ST is optional) | |
Operating Temperature | -10°C to 60°C | |
Storage Temperature | -20°C to 70°C | |
Work Humidity | <95% | |
APO | 10min | |
Dimensions | 16.5×8.0×3.5cm | |
Weight(g) | 280g |
Company Profile
About HYG Optics
The Haiyu Optics, founded in 2000, is focus on design and manufactured fiber optic communication products. It has developed a range of products including Indoor and outdoor optical cables, fiber optic jumpers, pigtails, connectors and adapters, network solution equipment like optic media converters, attenuators, tranceivers, optical models and other accessories. Widely used in telecom communication, mobile communication, network solution, radio and television, etc.
HYG Quality Assurance
Our ISO9001:2008 certified quality management systems have been refined for flexibility and efficiency, and produce a high quality, high reliability, low cost and diverse product range. Other quality system we complying with ISO14001, CE, Rohs and 5S system.
Advanced high precision test equipment: Insertion and return loss tester, 3D Interferometer.
The location
The company is located in Shenzhen, near by Hongkong, enjoying the convenient transportation. Our products are exported to USA, Germany, France, Russia, the UAE, Indonesia and so on. For our long-term development, our company cooperates with Corning, OFS, YFOC, CCTC, etc.
Our mission
QUALITY TO SURVIVE, INNOVATION FOR DEVELOPMENT.
