32 port gigabit ethernet switch
Specifications
1,low price and high quality
2,External power adapter supply
3,Steel case, desktop or wall-mounting design
4,welcome ODM/OEM
Description:
The PL-GS3008-A1 32-port Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files and other applications that have to move large files across the network almost instantly.
Features:
l Comply with IEEE 802.3, IEEE 802.3u and IEEE 802.3ab standards
l 8 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
l Support IEEE 802.3x flow control for full duplex mode and backpressure for half duplex mode
l Non-blocking switching architecture that forward and filter packets at wire-speed for maximum throughput
l Support MAC address auto-learning and auto-aging
l LED indicators for monitoring power, link and activity
l Steel case, desktop or wall-mounting design
l External power adapter supply
Specifications:
Standards | IEEE 802.3 , IEEE 802.3u , IEEE 802.3ab |
Data Transfer Rate | Ethernet:10Mbps (Half Duplex), 20Mbps (Full Duplex)Fast Ethernet:100Mbps (Half Duplex), 200Mbps (Full Duplex)Gigabit Ethernet:2000Mbps (Full Duplex) |
Network Media (Cable) | 10Base-T:UTP category 3,4,5 cable (maximum 100m) EIA/TIA-568 100Ù STP (maximum 100m) 100Base-Tx:UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ù STP (maximum 100m) 1000Base-T:UTP category 5, 5e cable (maximum 100m) |
Number of Ports | 8 10/100/1000Mbps Auto-Negotiation ports |
LED indicators | Power, Link/Act |
Transfer Method | Store-and-Forward |
MAC Address Learning | Automatically learning, automatically Update |
Frame Filtering and Forward Rate | 10Mbps: 14880pps, 100Mbps: 148800pps, 1000Mbps: 1488000pps |
Power Supply Output |
|
Dimensions (W×D×H) | (116×95×28mm) |
Environment | Operating Temperature:0 C~40 C (32 F~104 F) Storage Temperature:-40 C~70 C (-40 F~158 F) Operating Humidity:10%~90% non-condensing Storage humidity:5%~95% non-condensing |
