Specifications
16 channel Video optical transceiver1.IEEE802.3u.100BASE-T and 100 BASE-FL
2.16 channel and 1*SC/fc
3.10M/100Mbps
4.CE and
16 Channel Video and 1 Reverse Data Optical Transmitter and Receiver ,Singlemode, Single fiber,FC or SC connector
PRODUCT CHARACTERISTICS
1.8-bit digitally encoded and non-compression video transmission
2.Directly compatible with NTSC, PAL, and SECAM CCTV camera systems and support RS-232, RS- 422, and RS-485 data protocols
3.Support any high-resolution video signal
4.Automatic compatible PAL, NTSC and SECAM video system
5.Power supply and other parameter state indication, which can monitor the operation condition of system
6.Support no-damage regenerative trunk of video
7.Constant input optical power, and large dynamic range ,no Electrical or Optical Adjustments Required .
8.Special ASIC design .
9.Industry-grade of operating temperature from -10 to 75, which is applied to the different working environment
10.Hot-swap function
11.Stand-alone type or card-type installed in 19’’ 2U or 4U rack-mount chassis.
Specification
Video | |
Format |
NTSC,PAL, SECAM |
Impedance |
75ohm |
Voltage |
1.0V~1.5V |
Bandwidth |
8MHz – 3dB |
Differential Gain |
<1%(typical) |
Differential Phase |
<1°(typical) |
SNR |
≥70dB (weighted) |
Coding |
8 Bits |
Sampling Rate |
15M/bits |
Connector |
BNC |
Order Information
Optical | |||
Wavelength |
850/1310 Multimode |
1310/1550nm Single mode |
|
Fiber Type |
50/125μ |
62.5/125μ |
9/125μ |
Optical Output |
-18dBm |
-15dBm |
-13~-4dBm |
Receiver Sensitivity |
-26dBm |
-26dBm |
-30dBm |
Optical Budget |
8dB |
11dB |
18dB~35dB |
Optical Connector |
ST, SC, FC |
||
- SingleMode----Base Model: 0~20KM
- SingleMode----Extra Model: 100KM
Physical and Environmental | |
Power |
±5VDC, 1A |
Maximum Power |
6W |
MTBF |
> 10,000 Hours |
Operating Temperature |
-40°C ~ +70°C |
Storage Temperature |
-40°C ~ +80°C |
Relative Humidity |
0-95% |
Weight |
650g |
Size |
105mm L, 95mm W, 30mm H |
Related Products:
Factory overview:
