Specifications
outdoor water proof pigtail cable1.material:LSZH/PVC/PU
2.grade:IP68
3.LC/FC/ST/SC connectors
4.CE ,ROHS and ISO 9001
optical fber outdoor water proof pigtail cable for Network installation
Applied range
1 Optical fiber communication system
2 Optical access network
3 Optic-fiber Date Communication
4 Optical-fiber CATV
5 A local area network (LAN)
6 Test Equipment
Order informations
HYG-ST/ PC – ST/ PC/ SM/ 2C/ 3.0 – 1M
1 2 1 2 3 4 5 6
1 Connector types: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
2 Ferrule End-face: PC, APC
3 Fiber Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
4 Cable Quantity: “2C” means duplex,C means simple
5 Cable Diameter: 3.0mm, 2.0mm, 0.9mm
6 Length:1, 2, 3 meter or customized length
7 Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum
functional characteristics
1,2/4/6/8/12 core can be choose
2,subfeeder cable 2.0/3.0mm can be choose
3,High Tensile strength ,good ground
4,General water proof connector
5,Seal waterproof, tensile, corrosion resistance, suitable for field severe environment
6,Loose coupling, easy installation
7,Assembly of the connector type :FC,SC,ST,LC,MTRJ
8,Low instert loss,high return loss
Technical parameters:
Connector type |
SC/UPC,SC/APC,ST/UPC,FC/UPC,FC/APC,LC/UPC,LC/APC,MTRJ |
||||
Single mode |
Multi mode |
SM/APC |
MT-RJ(SM) |
MT-RJ(MM) |
|
Insert Loss |
≤0.3dB |
≤0.1dB |
≤0.3dB |
≤0.7dB |
≤0.45dB |
Return Loss |
≥50dB |
≥35dB |
≥60dB |
≥40dB |
≥25dB |
Repeat plug number |
≥1000times |
||||
Working temp |
-40°C~+70°C |
||||
Environmental Reliability Test
The performance of the patchcords has been carefully designed to meet the IEC standards, GR-326-CORE, in the test of optical characteristics, vibration test, thermal cycling, impact resistance, salt spray erosion, thermal aging, humidity resistance and others
Other pictures about our waterproof pigtail:
