Pull Fiber Ring Optic Patch Cord for Network Solution and Project

Pull Fiber Ring Optic Patch Cord for Network Solution and Project thumbnail-1
Pull Fiber Ring Optic Patch Cord for Network Solution and Project thumbnail-2
Pull Fiber Ring Optic Patch Cord for Network Solution and Project thumbnail-3
Pull Fiber Ring Optic Patch Cord for Network Solution and Project thumbnail-4
Pull Fiber Ring Optic Patch Cord for Network Solution and Project thumbnail-5
Pull Fiber Ring Optic Patch Cord for Network Solution and Project thumbnail-6
Pull Fiber Ring Optic Patch Cord for Network Solution and Project photo-1
Pull Fiber Ring Optic Patch Cord for Network Solution and Project photo-2
Pull Fiber Ring Optic Patch Cord for Network Solution and Project photo-3
Pull Fiber Ring Optic Patch Cord for Network Solution and Project photo-4
Pull Fiber Ring Optic Patch Cord for Network Solution and Project photo-5
Pull Fiber Ring Optic Patch Cord for Network Solution and Project photo-6
US$ 2.16 - 179 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HYG
Model Number:
HYG-ST-FC-SMDX-3.0-15M
Contact Supplier Request Quote Chat Now
Shenzhen Haiyu Optics Communication Equipment Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HYG
Model Number HYG-ST-FC-SMDX-3.0-15M

Specifications

pull ring fiber optic patch cord
1.material:LSZH/PVC/PU
2.for FTTH/FTTP/FTTX
3.LC/FC/ST/SC connectors
4.CE ,ROHS and ISO

pull ring fiber optic patch cord for Net work solutions



Applied range

1 Optical fiber communication system

2 Optical access network

3 Optic-fiber Date Communication

4 Optical-fiber CATV

5 A local area network (LAN)

6 Test Equipment

  fiber lc patch cord, fiber optic patch cord, pull ring fiber optic patch cord

Order informations

HYG-ST/ PC – ST/ PC/ SM/ 2C/ 3.0 – 1M

          1     2      1     2     3      4     5        6

1 Connector types:  FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA

2 Ferrule End-face: PC, APC

3 Fiber Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)

4 Cable Quantity: “2C” means duplex,C means simple

5 Cable Diameter: 3.0mm, 2.0mm, 0.9mm

6 Length:1, 2, 3 meter or customized length

7 Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum



Technical parameters

1 The min bending radius: 3.8 cm

2 Operating temperature range: - 40 ~ 85 °C

3 connector materials: ceramic plug core

4 Min bandwidth: 200 MHZ. Km / 850 nm, 500 MHZ. Km / 1300 nm

5 Repeat plug: < 0.2 dB, each 500 times plug

6 Min reflection loss: 20 db

7 Max return loss:-50dB

ITEM

TEST conditions

Single mode

Multi mode

Optical properties

Insertion loss

UPC

1.31um,LED

<=0.3dB

<= 0.3dB

APC

1.31um,LED

<= 0.3dB

<= 0.3dB

Return loss

UPC

1.31um,LED

>=50dB

>=35dB

APC

1.31um,LED

>=60dB



Mechanical properties

Impact test

HIGH:1.8   8 TIMES

<0.1dB

<0.1dB

Vibration experiment

5-50HZ,1mm Full amplitude

<0.1dB

<0.1dB

Plug life

More than 1000 times

<0.1dB

<0.1dB

tensile strength

>100N,

<0.1dB

<0.1dB

Environment characteristics

Temperature Cycling Test

-25°C~+70°C,5 circle

<0.2dB

<0.2dB

high-temperature test

+80°C,100 hours

<0.2dB

<0.2dB

Low-temperature test

-40°C,100 hours

<0.2dB

<0.2dB

Damp and hot test

+25°C~+65°C,Relative humidity 93%,100 hours

<0.2dB

<0.2dB



Using methods:

Pull ring type optical fiber patch cord, generally used for field bad environment, the reliability of the device to request a higher place, this product is pull-tab design, the use of plastic transparent casing ring optical fiber connector end and in the end make pull-tab type, which fiber optic jumper in the construction process can have the effect of long distance traction, protect the fiber connector is not damaged, and improve the efficiency of wiring.



 Other detail about FO pull  patch cord:



 pull fiber ring optic patch cord for network solution and projectpull fiber ring optic patch cord for network solution and projectpull fiber ring optic patch cord for network solution and projectpull fiber ring optic patch cord for network solution and projectpull fiber ring optic patch cord for network solution and projectpull fiber ring optic patch cord for network solution and project
