Power Outlay 10/1001000M Singlemode Single Fiber Transceiver

US$ 12 - 22 MOQ: 2 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

HYG

Model Number:

HYG-FOT-FC

Shenzhen Haiyu Optics Communication Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name HYG

Model Number HYG-FOT-FC

power OUTLAY 10/100/1000M Singlemode single fiber transceiver

Product features

The exchange chip development, and fully compatible with switch;

With 10/100 or 10/100 m / 100 m adaptive

With full duplex/half duplex adaptive function,

Support the straight line, cross line adaptive;

Light mouth default SC interface, can be customized to the FC, LC interface

Support 100 base - Fx or 1000 base - Fx optical fiber transmission, can share with other products;

Fully support and huawei, cisco SFP modules of communication;

Support single and double fiber transmission

Can be single use, also may be placed on a 2 u (14 tank) used in the frame

The outer power can choose AC 220 v/DC-48v;

Equipment lamp is complete, the working condition be clear at a glance,

Technical specifications

Interface electric mouth: RJ - 45 interface; Light mouth: SC/FC/LC interface

Optical fiber single-mode fiber or multimode fiber

Module type can choose 10/100 or 10/100 m / 1000 m single-mode and multimode double fiber modules or single mode single fiber module

Follow the standards and protocols:IEEE

Order information

Item	Velocity	Fiber		Distance	Fiber connector	Power
HYG100A-FE-MM-2	10/100M	MM	Two fiber	2km	SC/FC/LC	220V/-48V
HYG100A-FE-SM-25/40/60/80/100/120	10/100M	SM	Two fiber	25-120km	SC/FC/LC	220V/-48V
HYG100A-FE-SF13/15-25/40/60/80/100/120	10/100M	SM	Single fiber	25-120km	SC/FC/LC	220V/-48V
HYG1000A-GE-MM-5	10/100/1000M	MM	Two fiber	550m	SC/FC/LC	220V/-48V
HYG1000A-GE-SM-25/40/60/80/100	10/100/1000M	SM	Two fiber	20-100km	SC/FC/LC	220V/-48V
HYG1000A-GE-SF13/15-20/40/60/80	10/100/1000M	SM	Single fiber	20-80km	SC/FC/LC	220V/-48V
