Welcome to Sinofast
ShenZhen SinoFast Electronics co.,Ltd. was established in April,2005,After years'efforts, the company has expanded rapidly and kept Introducing new production equipments.We have also trained a professional team and perfected the quality management system ranging. the manufacture ability of our company is expanded rapidly. The annual output of double-sided and multi-layer PCB exceeds 100,000 square meters.,
How to work with us:
Certification
Why choose us?
1.PCB&PCBA factory directly.
2.We have the comprehensive quality control system.
3.Product in good price.
4.Quick turn delivery time from 48hours.
5.Certification(ISO/UL/RoHS).
6.8 years experience in exporting service.
7.We have no MOQ.
8.Product in high quality.Strict through theAOI(Automated Optical Inspection),QA/QC,fly porbe ,Etesting.
Product Technology
| High precision prototype | PCB bulk production | |
Max Layers | 1-28 layers | 1-14 layers | |
MIN Line width(mil) | 3mil | 4mil | |
MIN Line space(mil) | 3mil | 4mil | |
Min via (mechanical drilling) | Board thickness≤1.2mm | 0.15mm | 0.2mm |
Board thickness≤2.5mm | 0.2mm | 0.3mm | |
Board thickness>2.5mm | Aspect Ration≤13:1 | Aspect Ration≤13:1 | |
Aspect Ration | Aspect Ration≤13:1 | Aspect Ration≤13:1 | |
Board thickness | MAX | 8mm | 7mm |
MIN | 2 layers:0.2mm;4 layers:0.35mm;6 layers:0.55mm;8 layers:0.7mm;10 layers:0.9mm | 2 layers:0.2mm;4 layers:0.4mm;6 layers:0.6mm;8layers:0.8mm | |
MAX Board size | 610*1200mm | 610*1200mm | |
Max copper thickness | 0.5-6oz | 0.5-6oz | |
Immersion Gold/ Gold Plated Thickness | Immersion Gold:Au,1—8u” |
| |
Hole copper thick | 25um 1mil | 25um 1mil | |
Tolerance | Board thickness | Board thickness≤1.0mm:+/-0.1mm | Board thickness≤1.0mm:+/-0.1mm |
Outline Tolerance | ≤100mm:+/-0.1mm | ≤100mm:+/-0.13mm | |
Impedance | ±10% | ±10% | |
MIN Solder mask bridge | 0.08mm | 0.10mm | |
Plugging Vias capability | 0.25mm--0.60mm | 0.70mm--1.00mm | |
Description
1.Professional manufacturer of PCB and PCBA specialized in single-sided PCB,
double-sided PCB,multilayer PCB, PCB layout and design and PCB assembly.
2. Material Type: FR4,non-halogen material ,Aluminium Base,Cooper Base,
high frequency material ,Thick copper foil,94-V0(HB),PI Material,HIGH TG
.
3. Surface treatment: HAL,Immersion Gold,Immersion Tin,Immersion silver,Gold Finger,OSP,HAL(Immersion Gold,OSP,Immersion silver,Immersion Tin)+Gold Finger.
Factory show
Contact us
Floor 6,G building,HuaFeng industrial park, Tel:0755-27348887 Skype: plalex-
HangCheng Road.Xixiang,Shenzhen,China Cellphone:008615622237346 whatsapp:+8615622237346
If you want to know more about our company,please visit our webside:
Now send me your enquiry.
Your satisfaction , My pleasure!
