Full HD 1080P outdoor ip security camera 2 megapixel IR 20X optical zoom PTZ IP Camera
1)Encoding chip:TI DM368
2)Image sensor:1/3" Progressive Scan CMOS
3)1920*1080 (1080P) ;Focus F=4.70mm-94.0mm 20X optical zoom
4)12 array led IR distance 120 meter
5)H.264 High Profile/M-JPEG Coding,rate 96k-6M bps, max 30fps 1080P, Frame rate adjustable, supports three-stream
6)Level speed 200 degrees / sec, vertical speed 180 degrees / sec, 256 preset positions, support cruise, two limit the level of support scanning
7)Can support Onvif communication protocol and GB/T28181 network platform provides configuration client development kit SDK
8)Weight:6.1KG ,dimension:31*30*48(cm)
9)audio and SD card function optional
10)Wall mount or Ceiling mount bracket.
| Model | IPC-PTZ1001-20X | |||
| Camera | ||||
| Image Sensor | 1/3" Progressive Scan CMOS | |||
| Effective Pixels | 1920*1080 | |||
| Scanning System | Progressive | |||
| Electronic Shutter Speed | Auto/Manual, 1/3~1/10000s | |||
| Min. Illumination | Color: 0. 1Lux, B/W: 0.003Lux ; 0Lux(IR on) | |||
| S/N Ratio | >50dB | |||
| Camera Features | ||||
| Max. IR LEDs Length | IR Range 120 m | |||
| Day/Night | Auto(ICR) / Color / B/W | |||
| Backlight Compensation | BLC | |||
| White Balance | Auto | |||
| Gain Control | Auto/Manual | |||
| Noise Reduction | 2D | |||
| Privacy Masking | N/A | |||
| Lens | ||||
| Focal Length | 20X Zoom 4.7-94.0mm optional | |||
| Max Aperture | F1.6 | |||
| Angle of View | 81.1°-26.2° | |||
| Mount Type | MTV mount (Interchangeable Lens) | |||
| Video | ||||
| Compression | H.264 / MJPEG | |||
| Frame Rate | Main Stream | 1920*1080 30fps | ||
| Sub Stream | VGA 640*360 30FPS | |||
| Bit Rate | 128Kbps~8Mbps,Supports CBR/VBR | |||
| Audio | ||||
| Compression | G.711 | |||
| Interface | 1/1 channel In/Out | |||
| Network | ||||
| Ethernet | RJ-45 (10/100Base-T) | |||
| Protocol | TCP/IP , UDP , RTP , RTSP , RTCP , HTTP , DNS , DDNS , DHCP , FTP , NTP , PPPOE , SMTP , UPNP | |||
| ONVIF | ONVIF Ver. 2.0 | |||
| Max. User Access | 10 users | |||
| Smart Phone | iPhone, iPad, Android | |||
| General | ||||
| Power Supply | DC12V | |||
| Power Consumption | <6W | |||
| Working Environment | -10°C~+60°C, 10%~90% | |||
| Ingress Protection | IP66 | |||
| Dimension | 31*30*48(cm) | |||
| Weight | 6.1 KG | |||
| Package Dimension | ||||
| Package Weight | 6.3 KG | |||
| Approvals | CE FCC RoHS | |||
1.First send us an inquiry for quote or through trademanager,please be specific on products catagoy,products name ,color,quantity and your requirement about the products.
2.Then we will response to your request within 24 hours with an quotation sheet,payment term and delivery time .
3.After confirming all the information by you,we will prepare a copy of PI(proforma Invoice) or purchase agreement,we will attached the bank information in the PI.
4.After confirm your payment, we will arrange the products for you as soon as possible
