4CH AHD DVR KITS Support Dome/bullet HD CCTV Security Camera (JYR-9712AHD-Kit)
4CH AHD DVR KITS support dome/bullet HD CCTV security camera (JYR-9712AHD-Kit)
AHD Features:
4 X AHD Cameras
- IP66 Waterproof Bullet Camera
- Lens: Board Lens 3.6mm/F2.0
- IR LED: 24 x F5 IR LED
- IR Range: >30m
1x AHD DVR
- 1U 4ch AHD dvr
- Video recording channels & Resolution:4CH 720P Realtime
- Hybrid mode: 2x 720P AHD + 2 x 720P ip camera.
- Audio Input/Output:4/1
- Alarm Input/Output:2/1
- Support HDD:1pcs
- Video split:1/4
- AHD Specification :
Video Compression Format
H.264
Video System
NTSC / PAL
GUI OSD
YES
Video Input
4CH BNC input(composite video signal 1Vp-p 75Ω BNC)
Video Output
1CH VGA/1CH HDMI/1CH BNC
Audio Input/Output
1CH audio input,1CH audio output(RCA)
Maximum Recording Rate
720P:1280×720 pixels with 30FPS <NTSC> /1280×720 pixels with 25FPS <PAL>
Image Quality Setting
Supper Best,Well,Good,Medium,Normal and Bad
Hard Disk Storage
Support 1 SATA HDD
Alarm Input/Output
NO
Multiplex Operation
Live display/record/playback/backup/network transmit
Recording Mode
Manual/Timer/Motion/Alarm
Playback Mode
Multiple slow and rapid play speeds,manual and single-frame play modes,and support of drag the sliding bar to set.
Backup Device
USB flash drive,USB hard disk and network backup
Pre-alarm Recording
Recording for 10 seconds before alarming
Network Protocol
TCP/IP,PPPOE ,DDNS and NTP
Ethernet remote view
Support remote surveillance up to 10 users simultaneously
Size(mm)
260(L) x 44(H) x 221(W)
Packaging & ShippingBased on customer's demands to choose the most economical shipping terms.
Suggest:For sample order ship by Express,for mass order shipping by Air cago or by sea.
We have strong cooperation with DHL,FedEX,UPS,EMS,TNT.
Company InformationBrief Introduction of JONEY TECHNOLOGY CO.,LTD click to know more detail.
An High-tech enterprise that specialize in R & D, Production and Distribution of CCTV security products,Video&Audio Intercom products,access control products,etc .Through 10 years' effort ,We have established good cooperationship with customers worldwide from 150 different countries.
