4CH AHD DVR KITS support dome/bullet HD CCTV security camera (JYR-9712AHD-Kit)
AHD Features:
4 X AHD Cameras
- IP66 Waterproof Bullet Camera
- Lens: Board Lens 3.6mm/F2.0
- IR LED: 24 x F5 IR LED
- IR Range: >30m
1x AHD DVR
- 1U 4ch AHD dvr
- Video recording channels & Resolution:4CH 720P Realtime
- Hybrid mode: 2x 720P AHD + 2 x 720P ip camera.
- Audio Input/Output:4/1
- Alarm Input/Output:2/1
- Support HDD:1pcs
- Video split:1/4
- AHD Specification :
Video Compression Format
H.264
Video System
NTSC / PAL
GUI OSD
YES
Video Input
4CH BNC input(composite video signal 1Vp-p 75Ω BNC)
Video Output
1CH VGA/1CH HDMI/1CH BNC
Audio Input/Output
1CH audio input,1CH audio output(RCA)
Maximum Recording Rate
720P:1280×720 pixels with 30FPS <NTSC> /1280×720 pixels with 25FPS <PAL>
Image Quality Setting
Supper Best,Well,Good,Medium,Normal and Bad
Hard Disk Storage
Support 1 SATA HDD
Alarm Input/Output
NO
Multiplex Operation
Live display/record/playback/backup/network transmit
Recording Mode
Manual/Timer/Motion/Alarm
Playback Mode
Multiple slow and rapid play speeds,manual and single-frame play modes,and support of drag the sliding bar to set.
Backup Device
USB flash drive,USB hard disk and network backup
Pre-alarm Recording
Recording for 10 seconds before alarming
Network Protocol
TCP/IP,PPPOE ,DDNS and NTP
Ethernet remote view
Support remote surveillance up to 10 users simultaneously
Size(mm)
260(L) x 44(H) x 221(W)
