Help CenterFACTORY DIRECT SALES Coil Heater
US$ 1 - 10
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
shenzhouyb
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghaior ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cartridge Heater Element With ScrewNegotiableMOQ: 1 Piece -
Common Cartridge Heater With External Lead WireNegotiableMOQ: 1 Piece
-
U Type Finned Cartridge HeaterNegotiableMOQ: 1 Piece
-
Finned Heater Cartridge HeaterNegotiableMOQ: 1 Piece
-
Double U Tubular Heater for Electric Stream Rice MachineNegotiableMOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
shenzhouyb
| Heating cable table [Technical specifications] | ||||||||
| Heating cable Type | Sheath [450°C] | R per m [Ohm/m] | Cable Ø [mm] | Wall thickness [mm} | Max. Nom. Voltage [V] | Coil length [M] | Heating Conductor Material | Number of Conductors |
| CN | CuNi | 1.60 | 3.8 | 0.42 | 500 | CuNi44 | 1 | |
| CN | CuNi | 1.00 | 4.1 | 0.45 | 500 | CuNi44 | 1 | |
| CN | CuNi | 0.63 | 4.5 | 0.50 | 500 | CuNi44 | 1 | |
| CN | CuNi | 0.40 | 5.0 | 0.55 | 500 | CuNi44 | 1 | |
| CN | CuNi | 0.25 | 5.6 | 0.61 | 500 | CuNi44 | 1 | |
| CN | CuNi | 0.16 | 6.5 | 0.71 | 500 | CuNi44 | 1 | |
| Heating cable Type | Sheath [800°C] | R per m [Ohm/m] | Cable Ø [mm] | Wall thickness [mm} | Max. Nom. Voltage [V] | Coil length [M] | Heating Conductor Material | Number of Conductors |
| SS | 321 | 10.00 | 3.2 | 0.35 | 500 | 180 | NiCr80/20 | 1 |
| SS | 321 | 6.30 | 3.2 | 0.35 | 500 | 180 | NiCr80/20 | 1 |
| SS | 321 | 4.00 | 3.2 | 0.35 | 500 | 180 | NiCr80/20 | 1 |
| SS | 321 | 2.50 | 3.6 | 0.40 | 500 | 140 | NiCr80/20 | 1 |
| SS | 321 | 1.60 | 3.8 | 0.42 | 500 | 130 | NiCr80/20 | 1 |
| SS | 321 | 1.00 | 4.1 | 0.45 | 500 | 110 | NiCr80/20 | 1 |
| SS | 321 | 0.63 | 4.5 | 0.50 | 500 | 90 | NiCr80/20 | 1 |
| SS | 321 | 0.40 | 5.0 | 0.55 | 500 | 70 | NiCr80/20 | 1 |
| SS | 321 | 0.25 | 5.6 | 0.61 | 500 | 60 | NiCr80/20 | 1 |
| SS | 321 | 0.16 | 6.5 | 0.71 | 500 | 45 | NiCr80/20 | 1 |
| Heating cable Type | Sheath [1000°C] | R per m [Ohm/m] | Cable Ø [mm] | Wall thickness [mm} | Max. Nom. Voltage [V] | Coil length [M] | Heating Conductor Material | Number of Conductors |
| Inconel | Inconel600 | 10.00 | 3.2 | 0.35 | 500 | 150 | NiCr80/20 | 1 |
| Inconel | Inconel600 | 6.30 | 3.2 | 0.35 | 500 | 150 | NiCr80/20 | 1 |
| Inconel | Inconel600 | 4.00 | 3.2 | 0.35 | 500 | 150 | NiCr80/20 | 1 |
| Inconel | Inconel600 | 2.50 | 3.6 | 0.40 | 500 | 120 | NiCr80/20 | 1 |
| Inconel | Inconel600 | 1.60 | 3.8 | 0.42 | 500 | 110 | NiCr80/20 | 1 |
| Inconel | Inconel600 | 1.00 | 4.1 | 0.45 | 500 | 90 | NiCr80/20 | 1 |
| Inconel | Inconel600 | 0.63 | 4.5 | 0.50 | 500 | 70 | NiCr80/20 | 1 |
| Inconel | Inconel600 | 0.40 | 5.0 | 0.55 | 500 | 60 | NiCr80/20 | 1 |
| Inconel | Inconel600 | 0.25 | 5.6 | 0.61 | 500 | 50 | NiCr80/20 | 1 |
| Inconel | Inconel600 | 0.16 | 6.5 | 0.71 | 500 | 36 | NiCr80/20 | 1 |
| Heating cable Type | Sheath [450°C] | Corss section [mm²] | Cable Ø [mm] | Wall thickness [mm} | Max. Nom. Voltage [V] | Coil length [M] | Heating Conductor Material | Number of Conductors |
| 321 | 2.5(0.007Ω/m) | 5.3 | ±0.35 | 500 | Cu | 1 | ||
| 321 | 4.0(0.004Ω/m) | 5.9 | ±0.35 | 500 | Cu | 1 | ||
| 321 | 6.0(0.003Ω/m) | 6.4 | ±0.35 | 500 | Cu | 1 | ||
| Inconel600 | 2.5(0.007Ω/m) | 5.3 | ±0.35 | 500 | Cu | 1 | ||
| Inconel600 | 4.0(0.004Ω/m) | 5.9 | ±0.35 | 500 | Cu | 1 | ||
| Inconel600 | 6.0(0.003Ω/m) | 6.4 | ±0.35 | 500 | Cu | 1 | ||
