Warm White Color Temperature(CCT) Round Surface Mount LED Ceiling Light Diameter 300mm 24W,>1800LM, 80Ra Aluminium Alloy Frame
| Model No | 12W Round | 12W Square | 24W Round | 24W Square |
| Rated Wattage | 12.6W(12.2 -13.4) | 12.6(12.2-13.4) | 24W(22.5-26.5) | 24W(22.5-26.5) |
| Rate Voltage | 100-240Vac | 100-240Vac | 100-240Vac | 100-240Vac |
| Input Current | 250mA | 250mA | 500mA | 500mA |
| Frequency | 50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz |
| Power Factor | ≥0.4 | ≥0.4 | ≥0.4 | ≥0.4 |
| Driver Efficiency | ≥87% | ≥87% | ≥87% | ≥87% |
| EMC/EMI | / | / | / | / |
| Lumen | ≥900Lm | ≥900 Lm | ≥1800 Lm | ≥1800 Lm |
| CCT | 3000K/6500K | 3000K/6500K | 3000K/6500K | 3000K/6500K |
| SDCM | <6 | <6 | <6 | <6 |
| CRI Ra | ≥70 | ≥70 | ≥70 | ≥70 |
| Beam Angle | 120° | 120° | 120° | 120° |
| LEDs | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 |
| Lighting Source | Sideway leds | Sideway leds | Sideway leds | Sideway leds |
| Way of Installation | Surface mounting | Surface mounting | Surface mounting | Surface mounting |
| Fixture Color | White painting | White painting | White painting | White painting |
| Material | Al Alloy +PC | Al Alloy +PC | Al Alloy +PC | Al Alloy +PC |
| Working Temperature | -20~45℃ | -20~45℃ | -20~45℃ | -20~45℃ |
| Storage Temerature | -40~80℃ | -40~80℃ | -40~80℃ | -40~80℃ |
| Life Time | 20000hrs | 20000hrs | 20000hrs | 20000hrs |
| Protection | IP20 | IP20 | IP20 | IP20 |
G.W of Each Lamp |
500g±50g |
600g±50g |
1150g±100g |
1300g±100g |
Package |
Color Box |
Color Box |
Color Box |
Color Box |
Measurement |
190mmx45mmx190mm |
190mmx45mmx190mm |
307mmx45mmx190mm |
307mmx45mmx190mm |
Carton Size, NOS/CTN |
201mmx100mmx201mm/2 |
201mmx100mmx201mm/2 |
308mmx100mmx308mm/2 |
308mmx100mmx308mm/2 |
G.W of Each Carton |
1200g±100g |
1400g±100g |
2800g±100g |
3100g±100g |
1) Building or home decoration
2) Home use for lighting
3) Commercial Lighting
4) Emergency hallway lighting
5) Shopping mall, restaurant, hotel, meeting room etc
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 7 days, mass production time needs 20 working days.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
