Newest Type 4wd Small Agricultural Traktor

Newest Type 4wd Small Agricultural Traktor thumbnail-1
Newest Type 4wd Small Agricultural Traktor photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Zhengzhou Clyde Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 1830-2940
Certificate CE
Brand Name CLD
Model Number CLD254, CLD304,CLD354,CLD404
Place of Origin Henan, China
After-sales Service Provided Engineers available to service machinery overseas



Product Description

Newest type 4wd small agricultural traktor

 Main Features:

1. The use of a simple floor structure and an external divider is easy for maintenance;

2. The safety frame is optional;

3. The single-acting or double-acting clutch is optional;

4. The various gear configurations, such as 8+2, 8+8 are optional, and the velocity distribution is reasonable to meet different operating needs;

5. The synchronized shuttle shift is optional, and the operation is easy, flexible and reliable;

6. The operations of hydraulic steering, the mandrel cylinder front drive axle are easy and flexible.



 small agricultural traktor specification:



Model



CLD304

CLD354

CLD404

Drive type

4X4

Overall dimension LxWxh(mm)

2850X1560X1896

2900X1560X1896

Wheel base(mm)

1660

1690

Wheel tread(mm)

Front

1200

Rear

1200

Min. ground   clearance(mm)

300

Structure Weight(kg)

1250

1300

Clutch

Dry-friction, single   stage/Dry-friction, Two Stage

Suspention type

Rear three-point   suspention Class I

Gear box

(4+1)x2/(4+1)x2x2

Tire size

Front

6.0-16

6.0-16/6.5-16

Rear

9.5-24

9.5-24/11.2-24

Engine

Model

LD390

LD4L22

LD4L23

Type

Vertical Water   Cooledand 4-stroke

Power (kw)

22.1

25.8

29.4

Rev.(r/min)

2400

Fuel

Diesel Oil

PTO shaft

Rated speed(r/min)

540/720

Spline Size

I35 Rectangle Spline   With 6 teeth(6x28.91x34.79x8.69)





Newest type 30hp 4wd small agricultural traktor photos Newest type 4wd small agricultural traktorNewest type 4wd small agricultural traktorNewest type 4wd small agricultural traktorNewest type 4wd small agricultural traktor     Newest type 30hp 4wd small agricultural traktor with cabin  photos

Newest type 4wd small agricultural traktor Newest type 4wd small agricultural traktorNewest type 4wd small agricultural traktor

Newest type 30hp 4wd small agricultural traktor detail photosNewest type 4wd small agricultural traktorNewest type 4wd small agricultural traktorNewest type 4wd small agricultural traktorNewest type 4wd small agricultural traktor





Packaging & Shipping

Newest type 30hp 4wd small agricultural traktor made in China Newest type 4wd small agricultural traktorNewest type 4wd small agricultural traktor



Shipping by sea all over the world.

Packing standard, in the container.

We are able to ship the goods within 20 days receipt your deposit.







Our Services

  We can service OEM,  make to order, and one year after-sale service for you.



FAQ

Newest type 30hp 4wd small agricultural traktor



1,Is there any discount for customer?



Answer:  this type is one of our best-selling type, and in 2014,our company has made favorable price for support  exporting.



And if you add up your quantity needed, usually to 5 sets,then I can apply for a quantity price for you.



2,How about the shipment?



We are able to ship the goods within 20 days receipt your deposit.
