30hp 4wd Chinese Small Garden Tractors

30hp 4wd Chinese Small Garden Tractors thumbnail-1
30hp 4wd Chinese Small Garden Tractors photo-1
US$ 6,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Zhengzhou Clyde Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 14.7KW-19.6KW
Certificate CE
Brand Name CLYDE
Model Number CLD-700-CLD-1304
Place of Origin Henan, China
After-sales Service Provided Engineers available to service machinery overseas



Product Description

30hp 4wd chinese small garden tractors



Small garden tractor main features:



1.Adopt famous engine,good reliability,lower oil consumption.



2.Non independent power take off device,smooth transmission,large capacity.



3.Full hydraulicsteering,opreation flexible,reliable,and save energy.



4.New streamlined appearance,modern,fashion.



5.ROPS,Canopy,Cabin,A/C,Swing bar ect,can be selected.





garden tractor specification:



Model

CLD204

CLD254

CLD304

CLD354

CLD404

Type

4*4

4*4

4*4

4*4

4*4

Dimensions of tractor(mm)

Length

2700

2700

2700

2700

2700

Width

1260

1260

1260

1260

1260

Height

1200

1200

1200

1200

1200

Tread

Front Wheel

1000

1000

1000

1000

1000

Rear Wheel

1000

1000

1000

1000

1000

Wheel Base

1600

1600

1600

1650

1650

Min. Ground Clearance

260

260

280

280

280

Dry Mass(kg)

1150

1170

1250

1300

1300

Engine

Model

JD295

JD2100

LD390

LD4L22

LD4L23

Type

Vertical Water Cooledand 4-stroke

Rated Power

14.72

18.4

22.1

25.8

29.4

Rated Rev(r/min)

2300

2400

2400

2400

2400

Fuel

Diesel Oil

Tire

Front Wheel

6.00-12

6.00-12

6.00-12

6.00-12

6.00-12

Rear Wheel

8.3-24

8.3-24

8.3-24

8.3-24

8.3-24

Clutch

Dry-friction,single stage or Dry-friction,Two Stage

Steering

Mechanical Type or Hydraulic Type

Transmission Box

(4+1)×2

Suspension Type

Rear three-point suspension Class 0

PTO shaft

Type and Rev(r/min)



Non-independent type720 or Non-independenttype540/720

SplineSize



I35 Rectangle   Spline With 6 teeth (6×28.91×34.79×8.69)



Garden tractor photos



Red agriculture tractor

30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors

Green small garden tractors

30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors30hp 4wd chinese small garden tractors



4wd tractor delivery

 30hp 4wd chinese small garden tractors









Packaging & Shipping

Chinese tractors packaging detail: Iron Crate or as customer's requirement .

Small garden tractor tractor shipping:All of the goods produce by the order.



Our Services

  Warranty period is 1 year after the goods delivery your port .





Service contact

We Supply 24 hours online service, if you have any questions on  4WD Agricultural tractor and other farm machinery, do not hesitate to contect.

Zhengzhou Clyde Machinery Co., Ltd

Ms.jessie liang

Tel:0086 186 25561571

Skype: jessie.liang 2

30hp 4wd chinese small garden tractors
