24W Railway Single Output DC to DC Electronic Led Converter

Name: 24W Railway Single Output DC to DC Electronic Led Converter
Brand: XZ-POWER
SKU: 133154017
Availability: InStock

US$ 1 - 8 MOQ: 200 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

XZ-POWER

Model Number:

XZ-CA24B

Shenzhen Xiezhen Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name XZ-POWER

Model Number XZ-CA24B

Output Power Other, 24W

Output Type Single

Input Voltage Other, 200-240V/100-240V

Output Voltage 27~42V

Output Frequency 47-63HZ

Output Current 100-650mA OR 100-550mA

24W Railway Single Output DC to DC electronic led converter

1. Ultra thin led driver for ceiling light, spot light, panel light ;

2.Hight efficiency=88%;

3. High PF>0.9;

4. Output Voltage Range 27-42V;

5. Output Current Range 100-650mA OR 100-550mA ;

6. Lead Time 7~15 days;

7. 100% burn-in testing before shipment;

8. good for ETL testing and Energy Star test;

9. Low THD.

24W Ultra Thin Constant Current Output LED Driver XZ-CA24B
Output DC Voltage Range	27-42V	27-42V
Output Rated Current Range	100-650mA	100-550mA
Output Rated Power	up to 24W
Output Load Regulation	±5%
Output Turn On Time	0.98S max. @ input 100 - 240 Vac & max. load
Input Voltage Range	200-240Vac	100-240Vac
Input Frequency Range	47-63HZ
Input Power Factot Typ.@230V	0.9 mini @ full load
Efficiency Typ.@230V	88% mini @ full load
AC Current	0.35A max. @ input 100Vac & max. load
Input Inrush Current (Typ.)	30A max. @ input 277Vac & max. load
THD (Total Harmonic Dist.)
Protection	Short circuit/over current/over voltage
Certificate	TUV SAA CB CE
Warranty	3 year/ 5 year
Dimension	L98.5W46.5H15mm
