W-TEL outdoor equipment telecom UPS inverter battery cabinet

Specifications

outdoor equipment telecom inverter battery cabinet
IP65 EMC protection
airconditioner system
IS0 9001:2000
Military design

W-TEL ODT- series telecom outdoor rack cabinet:

 outdoor telecom equipment rack cabinet

W-TEL outdoor equipment telecom UPS inverter battery cabinet

W-TEL telecom equipment outdoor UPS inverter battery cabinet
IP65 EMC protection
airconditioner system
IS0 9001:2000
Military design

Maily used in the field of traffic, CATV, electric power etc.Can be used under different conditions: gale, rain, snow, hail, frost, smog and solar radiate etc.The main part of the cabinet is made of magnesium and aluminum alloy .

1>Adapts to frame design of "Sandwich" .Covered with magnesium and good capability of

    preservation



2>Introduces the four-point latch-up structure to strengthen safety of cabinet Thermal insulating

     material enchased in component

3>Can prevent conductive heat like outdoor ultraviolet radiation from infiltrating into the cabinet

     effectively

4>Select professional air conditioner with modulation of constant temperature, humidity and setting

    of heating to ensure cabinet is provided with best operating environment

5>Inside is composed of standard 19-21 inch frame



Temperature management, control system, power supply system, entrance guard, environment supervisory system and wiring unit module

Cabinet meets the requirements of IP65 level of protection



Poduct Specifications:



l        Waterproof, dust proof:

Sealed by import seal belt, waterproof design and air filter instrument realize the efficient protection,IP 55

l        Temperature and humidity solution:

We adopt different components to control temperature and humidity to ensure the best working condition inside the cabinet.

l        Anti-corruption solution:

The surface of the cabinet , fan and air-condition are made of aluminum alloy, can protect from UV and salt material.

l        Machine protection solution:

The cabinet is designed specifically to protect it from human damage, earthquick and other damages.

l        EMC protection

Dealed with hydrochloric acid, use EMC seal belt , special earthing to avoid and reduce creepage.





Divided into four parts:

equipment zone, wiring zone, cell zone and electric source zone.



Adopt special imported outdoor industrial air-conditioner.

The perfect earthing system to protect it from thunder.

The cabinet meets the requirements of IP 65 protection level.

The enshroud dustproof net is installed in the air circulation system to protect the entry of dust and insects.

Special A4 size material box and unique PC panel, easy maintainance and operating.





We are a hi-tech enterprise (headquarter - Hong Kong) which is specialized in R&D, manufacturing, marketing of communication network physical connection equipment, providing a full range of physical connection solutions and products. Nowadays, the main products of our company are Fiber Optic Closure, Optic Fiber distribution (Terminal) Box, Optical Passive Components. During these last years we have successfully R&D the outdoor telecom cabinet (fan type, heat exchange type and air-conditioner type) and the FTTx solving project. Our products are widely used in the industries of telecom, Netcom, china mobile, underground, highway, airport project and the controlling system of railway.

Our company has been accredited the certification of quality management system of ISO9001:2000 and the TLC.
