copper electroplating steel(CCS) Wire Electroplating Machine
- 6 Set / Sets per Month
- Shanghai or Zhangjiagang
- T/T
-
Feiyide Mini Manual Silver Barrel Electroplating Production Line
-
Feiyide electroplating rectifier for chrome zinc plating
-
Feiyide Electroplating Equipment Zinc Chrome Screw Plating Equipment
-
Feiyide Titanium anode basket,electroplating machine ,positive pole device
-
Feiyide Nickel Plating Equipment Electroplating Machine for Nuts Bolts
-
Feiyide Continuous Gold Plating Brushing Sets
Product Details
| Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | Liya |
| Dimension(L*W*H): | 18000*1200*1400 | Weight: | 4000kg | Certification: | ISO,CE |
| Warranty: | 12months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Wire LY-3000A/5000A/8000A Electroplating Machine
Usage for LY-3000A/5000A/8000A Electroplating Machine:
LY-3000A/5000A/8000A Electroplating Machine can make copper electroplating steel(CCS) wire,copper electroplating brass(Cu-Cu) wire and copper electroplating aluminium(CCA) wire.
Technical Parameter for LY-3000A/5000A/8000A Electroplating Machine :
Machine Type | 3000A | 5000A | 8000A |
Control System | Button | ||
Main Power Control | Controlled by Electric Motor | ||
Take-up Power Control | Controlled by Torque Motor | ||
Diameter of Wire (mm) | Ø1.00-Ø1.20 | Ø1.20-Ø1.60 | Ø1.60-Ø3.00 |
Main Motor (KW) | 4 | 5.5/7.5 | 7.5/11 |
Take-up Motor | YLJ132-16 | YLJ132-40 | YLJ132-40 |
Take-up Method | Shaft/ Axis | ||
Traversing | Palm Shaft | ||
Transmission | Tri-Angle Belt Chain | ||
Speed (m/min) | 0-100 | 0-100 | 0-100 |
Rectifier (A) | 3000 | 5000 | 8000 |
Dimension (L×W×H)(mm) | 18000×1200×1400 | 22000×1600×1600 | 23000×1800×1600 |
Weight (KG) | 4000 | 5000 | 65000 |
Quantity of Wire | Sing Head or Multi Heads | ||
After-Sale Service:
1. In order to help customers are able to operate the machine correctly, trainings on operation, maintenance and simple repair can be supplied if necessary.
2. Mechanical parts are provided one-year limited warranty, and electrical parts are six-month since the shipment date.
We shall work with you as a team and to win as a team.
We provide not only quality products but also best service to you.
Quality, Innovation and Service
