Over 17 years experience factory supply K oval professional t shirt printing machine
Color |
6 colors |
8 colors |
10 colors |
12 colors |
16 colors |
||
Table number |
28 |
30 |
36 |
42 |
54 |
||
Table size(mm) |
700*900mm |
700*900mm |
700*900mm |
700*900mm |
700*900mm |
||
Plate material |
Aluminum alloy honeycomb panel |
Aluminum alloy honeycomb panel |
Aluminum alloy honeycomb panel |
Aluminum alloy honeycomb panel |
Aluminum alloy honeycomb panel |
||
maximum printing |
650*800mm |
650*800mm |
650*800mm |
650*800mm |
650*800mm |
||
area(mm) |
|||||||
Max frame |
800*1050mm |
800*1050mm |
800*1050mm |
800*1050mm |
800*1050mm |
||
size(mm) |
|||||||
Max speed |
400-650pcs/h |
400-650 pcs/h |
400-650 pcs/h |
400-650 pcs/h |
400-650 pcs/h |
||
|
|||||||
Machine length |
11.5m |
13.5m |
15.8m |
18m |
22.5m |
||
Machine width |
3.9m |
3.9m |
3.9m |
3.9m |
3.9m |
||
Power supply |
3 phase,380V |
3 phase,380V |
3 phase,380V |
3 phase,380V |
3 phase,380V |
||
Power |
5.5KW |
5.8KW |
6.5KW |
7.1KW |
8.0KW |
||
Dryer power |
65KW |
86KW |
108KW |
130KW |
173KW |
||
Air Pressure specifications |
6bar/8bar(Must pass through the drying and filtering) |
||||||
Gas consumption |
650L/min |
710L/min |
780L/min |
850L/min |
980L/min |
||
weight |
3500kg |
4000kg |
4500 kg |
5000 kg |
6500 kg |
||
Overprint accuracy |
0.05mm |
0.05mm |
0.05mm |
0.05mm |
0.05mm |
||
Questions and answers:
A. Honeycomb board good place:
1. Light weight, fast rotation, the printing speed;
2. After drying, heat quickly, not blocking net.
B. good place to use synchronous belt.
For example, bike, bicycle chains are elongated and synchronous belt, there are more than 100 steel wire, not elongated.
C. Flocking need how much money?
15000RMB / head, but don't add , too hair
D. how is the printing speed?
Mainly depends on the size of the pattern and drying what kinds of pulp (drying speed)
E. How is the speed to adjust the machine?
12 color, skilled master for 30-40 minutes
F. warranty time?
1 year
|
|
|
|
