Specifications
convenient,high quality,flexible,easy to operate and maintain,power saving,full automation,efficient,wide-ranging application
Characteristics:
1)Printing transmission is driven by the electric motor,synchronous belt drive.
2)Action sensitive, speed can be adjusted. Machine up and down is driven by the electric motor, frequency control. Smooth operation.
3) Scraper and scraping blade have a air pressure governor, the thickness of the printing can be adjusted.
4) Vacuum adsorption print.
5)The working table has a vernier regulation system(can moveleft and right ,forward and backward)that makes registration more correctly and simply.
6) With security devices to make the head printing stop on the upper part position that is more reliable and safer.
7) The electronic control unit(ECU)is central control by the microcomputer, the operation of complete applicance is simpler and more flexible, easy to maintain.
Application Scope:
Sign name plate ,Caijing glass ,Light Guide plate,The lens window,Membrane switches
technical parameters:
Model |
YKP-4060II |
YKP-5070II |
YKP-6090II |
Workbench Area (mm²) |
5000×700 |
600×800 |
700×1000 |
Max Print Area (mm²) |
400×600 |
500×700 |
600×900 |
Max Screen Size(mm) |
700×850 |
700×900 |
800×1200 |
Accuracy(mm) |
±0.05 |
±0.05 |
±0.05 |
Registering Accuracy(mm) |
±0.01 |
±0.01 |
±0.01 |
Printing Speed(mm/sce) |
80~160 |
80~160 |
80~160 |
Printing pressure(kgf/cm²) |
4.0~8.0 |
4.0~8.0 |
4.0~8.0 |
Source Power (kw) |
2.3 |
2.3 |
2.3 |
Rated Power (V) |
380 |
380 |
380 |
Highest NO of Printing(Hr) |
400-600 |
400-600 |
400-600 |
Thickness of printing stock |
<50mm |
<50mm |
<50mm |
Weight(kg) |
|
|
|
Dimension (mm) L×W×H |
1200×870×1620 |
1300×970×1620 |
1500×1070×1750 |
|
|
|
|
We can manufacture according to customer’s requirements. We also have the model of YKP-80120,YKP-80160,YKP80-220.
