Help CenterPrinting Press Machines for Circuit Board Printing With High Accuracy
Related Products
-
Serigraph Printing Machine Professional ManufacturerUS$ 4,000 - 6,000MOQ: 1 Set -
Manual Semi Automatic Digital Flex Printing Machine PriceUS$ 5,000 - 8,000MOQ: 1 Set
-
Cheap Manual Screen Printing TableUS$ 4,000 - 6,000MOQ: 1 Set
-
Price of Semi-automatic Screen PrinterUS$ 4,000 - 6,000MOQ: 1 Set
-
Oblique Arm Screen Printing Machine YKP6090/70100/90120US$ 100 - 6,000MOQ: 1 Set
Specifications
1.high quality and mature technology flat silk screen printing machine2.Brand assurance
3.Stable performance
4.CE manufactur
1.Characteristics:
Printing transmission is driven by the electric motor,synchronous belt drive.
Action sensitive, speed can be adjusted. Machine up and down is driven by the electric motor, frequency control. Smooth operation.
Scraper and scraping blade have a air pressure governor, the thickness of the printing can be adjusted.
Vacuum adsorption print.
The working table has a vernier regulation system(can moveleft and right ,forward and backward)that makes registration more correctly and simply.
With security devices to make the head printing stop on the upper part position that is more reliable and safer.
The electronic control unit(ECU)is central control by the microcomputer, the operation of complete applicance is simpler and more flexible, easy to maintain.
2.Application Scope:
Sign name plate ,Caijing glass ,Light Guide plate ,The lens window,Membrane switches
3.Accessories:
Toolbox | six-angle-wrench, screwdriver, activity-wrench, manual, protective tube | 1pcs/each |
scraper and scraping blade rubber strip |
| 1set |
scraper and scraping blade |
| 1set |
Air tube | Φ8 | 5m |
Power outlet |
| 1pcs |
nical parameters:
Model | YKP-4060II | YKP-5070II | YKP-6090II |
Workbench Area (mm²) | 5000×700 | 600×800 | 700×1000 |
Max Print Area (mm²) | 400×600 | 500×700 | 600×900 |
Max Screen Size(mm) | 700×850 | 700×900 | 800×1200 |
Accuracy(mm) | ±0.05 | ±0.05 | ±0.05 |
Registering Accuracy(mm) | ±0.01 | ±0.01 | ±0.01 |
Printing Speed(mm/sce) | 80~160 | 80~160 | 80~160 |
Printing pressure(kgf/cm²) | 4.0~8.0 | 4.0~8.0 | 4.0~8.0 |
Source Power (kw) | 2.3 | 2.3 | 2.3 |
Rated Power (V) | 380 | 380 | 380 |
Highest NO of Printing(Hr) | 400-600 | 400-600 | 400-600 |
Thickness of printing stock | 50mm | 50mm | 50mm |
Weight(kg) |
|
|
|
Dimension (mm) L×W×H | 1200×870×1620 | 1300×970×1620 | 1500×1070×1750 |
|
|
|
|
TIPS:We can manufacture according to customer’s requirements. We also have the model of YKP-80120,YKP-80160,YKP80-220.
