Home > Products > semi-auto screen printer > high pression direct from factory paper/glass/film/plastic/PVC/PP photo printing machine prices
high pression direct from factory paper/glass/film/plastic/PVC/PP photo printing machine prices
- 10 Set / Sets per Month
- shenzhen
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | Shenzhen Scien-JC Printing Machinery Manufacturing Co., Ltd |
Model Number: | YKP4060II YKP5070II YKP6090II | Usage: | Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer, Other, Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer, sign name plate caijing glass light guide plate the lens window | Automatic Grade: | Semi-Automatic |
Voltage: | 380V | Gross Power: | 2.3KW | Dimensions(L*W*H): | 1200mm*870mm*1620mm 1300mm*970mm*1620mm 1500mm*1070mm*1750mm |
Weight: | / | Certification: | CE | Warranty: | One year warranty |
After-sales Service Provided: | Overseas third-party support available |
Product Description
Characteristics:
1)Printing transmission is driven by the electric motor,synchronous belt drive.
2)Action sensitive, speed can be adjusted. Machine up and down is driven by the electric motor, frequency control. Smooth operation.
3) Scraper and scraping blade have a air pressure governor, the thickness of the printing can be adjusted.
4) Vacuum adsorption print.
5)The working table has a vernier regulation system(can moveleft and right ,forward and backward)that makes registration more correctly and simply.
6) With security devices to make the head printing stop on the upper part position that is more reliable and safer.
7) The electronic control unit(ECU)is central control by the microcomputer, the operation of complete applicance is simpler and more flexible, easy to maintain.
Application Scope:
Sign name plate ,Caijing glass ,Light Guide plate,The lens window,Membrane switches
technical parameters:
Model | YKP-4060II | YKP-5070II | YKP-6090II |
Workbench Area (mm²) | 5000×700 | 600×800 | 700×1000 |
Max Print Area (mm²) | 400×600 | 500×700 | 600×900 |
Max Screen Size(mm) | 700×850 | 700×900 | 800×1200 |
Accuracy(mm) | ±0.05 | ±0.05 | ±0.05 |
Registering Accuracy(mm) | ±0.01 | ±0.01 | ±0.01 |
Printing Speed(mm/sce) | 80~160 | 80~160 | 80~160 |
Printing pressure(kgf/cm²) | 4.0~8.0 | 4.0~8.0 | 4.0~8.0 |
Source Power (kw) | 2.3 | 2.3 | 2.3 |
Rated Power (V) | 380 | 380 | 380 |
Highest NO of Printing(Hr) | 400-600 | 400-600 | 400-600 |
Thickness of printing stock | <50mm | <50mm | <50mm |
Weight(kg) |
|
|
|
Dimension (mm) L×W×H | 1200×870×1620 | 1300×970×1620 | 1500×1070×1750 |
|
|
|
|
We can manufacture according to customer’s requirements. We also have the model of YKP-80120,YKP-80160,YKP80-220.
