Help CenterAutomatic Acrylic Printing Screen Printer Made in China CE Factory
Related Products
-
Heat Transfer Paper Auto Screen Printing MachineUS$ 45,000 - 60,000MOQ: 1 Set -
Big Size Flat Table Automatic Textile PrinterUS$ 10,000 - 50,000MOQ: 1 Set
-
Big Size Flat Table Automatic Textile Printing MachineUS$ 10,000 - 50,000MOQ: 1 Set
-
China Manufacturer Seven-colors Acrylic Solvent Printing MachineUS$ 1,000 - 300,000MOQ: 1 Set
-
Five-colours Solvent Film Printing MachineNegotiableMOQ: 1 Set
Specifications
1.Fully automatic Acrylic screen printing machine2.No scrap rate
3.saving staff and scrap cost
4.Brand assurance
1. Application Scope:
Apply to the plate glass,mobile phone lenses, display, electrical panel, name plate ,acrylic film and other kinds of screen printing materials, especially for soft materials and dot printing obvious advantages
2. Characteristics:
System adopts PLC and man-machine interface centralized control, stable performance
Table is made of pure Aluminium die-casting forming, beautiful appearance, standard, spread fast, light weight, easy to replace
Printing power offer by electric frequency, ball screw drive, blance powerful
Bedplate and screen automatic positioning, position more precise and reduce scrap
Net frame is increased fine-tune function, can make up the error caused by the change of the tension
Closed loop type vacuum suction system, the first in the world , ensure full super adsorption substrates
Adopts the positioning plate, reduce error produced by the process, to ensure the quality of plate making
Each location manual operation independent and the main operation box adopts touch screen operation, high automated, simple operation, (ordinary staff can operate),use less people(1-3people)
Separate enclosed printing area, reduce the waste gas diffusion, more environmentally
Product offer the exhaust system and humidifying window, can be choosed by customer
3. technical parameters:
Model |
Seven-colors acrylic solvent printing machine |
The number of color overprint |
1~10colors |
Drying method |
Far infrared, mid infrared and ultraviolet drying |
Workbench Area (mm²) |
880×826 |
Max Print Area (mm²) |
500×700 |
Max Screen Size(mm) |
880×826 |
Accuracy(mm) |
±0.05 |
Thickness of printing stock(mm) |
0~10(Special thickness can be customized) |
Printing Speed (printing times/h) |
100~3000 |
Work Pressure (Mpa) |
0.4~0.8 |
Rated Power (V/Hz) |
380/50 |
Source Power (kw) |
The Host Power 4.5 kw, Drying Power 6-12 kw , Vacuum Pump 3-6 kw |
Vacuum Flow(m3/h) |
100~200(Inhale version) |
Air Consumption(cm3/time) |
6600(suggest to equip with 7.5kW air compressor) |
Dimension (mm) L×W×H |
(8500-16000)×1145×1600 |
Weight (kg) |
3000~5000 |
We can manufacture according to customer’s requirements
