Help CenterAutomatic Punching Machine CCD-1007
Related Products
Specifications
High accuracy ,fast speed,stable,option for the Clamp or vacuum adsorption is availableAutomatic punching machine CCD-1007
1. Application Scope:
Punching machine is mainly used in printing industry, circuit boards, electronic, nameplates, signs, packaging industry positioning hole processing. In the PC, PVC, PE, PET, FPC, flexible circuit boards, membrane switch, mobile phone lens, film, aluminum and other materials on automatic accurate positioning hole. The device is using a computer, CCD industrial camera automatic search position hole punching, automatic calibration position so as to realize automation, improve efficiency, reduce the inaccurate punching of non-conforming waste
2. Characteristics:
1)High precision punch: adopt computer control, the CCD camera positioning, imported precision screw guide transmission, equipped with precision punching, imported cylinder control punch, ensure the punching error is less than 0.008 mm
2)Punching speed: use our company independent development of VT series software, high stability of motor, high operation industrial computer, drilling speed can be up to 0.4s / hole, integrated speed can reach 4000 holes/hour
3)High stability: the driving part adopts the Japan THK guide screw, high precision long life, imported cylinder control punch, a strong software development team to ensure the long-term stability and equipment to ensure the accuracy of holing for life.
4)Clamp or vacuum adsorption optional: only one, industry first, solve the mobile phone lens, mobile phone keys, mobile phone touch screen/panel and other products can't pressure problem.
5)Adjustable positioning hole, positioning hole deviation between mold, can calibration location hole deviation between mold and (increase or decrease), positioning hole and the distance between the top and bottom or so mold can be adjust, with digital indication commissioning, operation is simple, accurate to 0.000001 is wrong, the technology has solved the problem of design error, mould deviation ect.
6)Recognition ability is very strong: can automatically identify semicircle, the imperfect circle file and ghosting, reflective material and so on .Any pattern included.
3. Technical Parameters:
Model |
CCD-1007 |
Speed(s/hole) |
<0.4 |
Accuracy(mm) |
<0.008 |
Sheet sizes (mm) |
Max width:600; Unlimited length |
The thickness of the plate(mm) |
0.01~5 According to the composition of the material |
Action way |
Pneumatic and motor to move |
Moving parts |
Japan imported guide rail + screw |
The max impact (kg) |
100 |
The light source |
Up and down LED |
Fixed way |
Floor (with castor) |
Power |
AC220V/50Hz/500W |
Weight(kg) |
About 200 |
Dimensions(mm)L×W×H |
1100×800×1200 |
|
|
Tip: We can manufacture according to customer’s requirements.
4.Fair Show
Any questions pls feel free to contact me.And welcome to visit our factory.
