8.4V 3A Li-ion Battery Charger 100-240V 50-60Hz Charger 8.4V 3A Lithium Battery Charger

8.4V 3A Li-ion Battery Charger 100-240V 50-60Hz Charger 8.4V 3A Lithium Battery Charger thumbnail-1
8.4V 3A Li-ion Battery Charger 100-240V 50-60Hz Charger 8.4V 3A Lithium Battery Charger photo-1
US$ 1 - 6 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Brand Name:
MESSO
Model Number:
MSO0843000C
Use:
Standard Battery
Contact Supplier Request Quote Chat Now
Shenzhen Messo Technology Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name MESSO
Model Number MSO0843000C
Use Standard Battery
Place of Origin Guangdong, China



ITEM NAME 8.4V 3A Lithium Battery Charger
Features:

. 25.2W Lithium Battery Charger
. Worldwide AC Input Voltage 100-240V
. Output Voltage Range: 8.4V
. Output Current Range: 3A
. Red/Green Led Light Show
. Short-Circuit/Overvoltage/Overcurrent Protection
. Meet CE RoHS Safety Standard
. Warranty: 2 years
INPUT
Input Voltage 85-264VAC
Input Frequency 47-60Hz
Input Current 0.5A Max at 110VAC
Inrush Current 40A Max at 230VAC
Earth Leakage Current Class II
No Load Input Power <0.3W
OUTPUT
Output Voltage 8.4V 3A
Start Up Delay 1.3s Max
Start Up Rise Time 15ms Typical
Hold Up Time 10ms Min at full load 115VAC
Line Regulation +/-1% Max
Load Regulation +/-5% Max
Ripple Noise 1% Max
Overvoltage Protection 150% Of Nominal Output
Overcurrent Protection 150% Of Nominal Output
Short Circuit Protection Trip And Restart
GENERAL
Isolation 3000VAC Input To Output
MTBF 50KHrs To MIL-HDBK-217F At 25OC
Operation Temperature -10 To + 70 OC
Cooling Natural Convection
Operating Humidity 5% To 90% RH,Non-Condensing
Storage Temperature -40 To +90 OC
Shock 30g,Half Sine,6 Axes
Vibration 5-50Hz,Accelerated 7.35m/s
Altitude 3000m
EMC & SAFETY
Emissions EN55022
Harmonic Currents EN61000-3-2,Class A
Voltage Flicker EN61000-3-3
ESD Immunity EN61000-4-2
Radiated Immunity EN61000-4-3
EFT/Burst EN61000-4-4
Surge EN61000-4-5
Conducted Immunity EN61000-4-6
Magnetic Field EN61000-4-8
Dips Interruptions EN61000-4-11
Dimensions & Weight
Dimensions 3.74 in x 0.74 in x 1.10 in ( 9.5cm x 4.5cm x 2.8cm )
Box Size / PCS 8.27 in x 3.94 in x 2.36 in ( 21cm x 10cm x 6cm)
Carton Size / CTN 17.32 in x 16.54 in x 12.60 in (44cm x 42cm x 32cm)
Package BOX+CARTON 40PCS/CTN
Packing List
1 x Paper Box
1 x Adapter
Terms of payment
1) T/T: Internet bank, telegraphic transfer
2) Western Union
3) Paypal
4) Ali Escow
5) Irrevocable L/C draft at sight
Shipping Methods
Express/Air transportation: DHL, FEDEX,USP, EMS, TNT, ARAMES / Sea Transportation / Land Transportation

8.4V 3A Li-ion Battery Charger 100-240V 50-60Hz Charger 8.4V 3A Lithium Battery Charger

8.4V 3A Li-ion Battery Charger 100-240V 50-60Hz Charger 8.4V 3A Lithium Battery Charger

8.4V 3A Li-ion Battery Charger 100-240V 50-60Hz Charger 8.4V 3A Lithium Battery Charger







8.4V 3A Li-ion Battery Charger 100-240V 50-60Hz Charger 8.4V 3A Lithium Battery Charger





8.4V 3A Li-ion Battery Charger 100-240V 50-60Hz Charger 8.4V 3A Lithium Battery Charger
