6V 500mA Adapter 3W Led Lighting Light Lamp Bulb Strip Flashlight AC DC Power Adapter

Name: 6V 500mA Adapter 3W Led Lighting Light Lamp Bulb Strip Flashlight AC DC Power Adapter
Brand: MESSO
Price: USD $1 - 2 / Piece

FOB Price

USD $1 - $2 / Piece

500 Pieces(Min.Order)

Supply Ability 500000 Piece / Pieces per Month
Port Shenzhen/Hongkong
Payment Terms:Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	MESSO	Model Number:	MSO0600500B
Output Type:	DC	Connection:	Plug In

Product Description

ITEM NAME	6V 500mA AC DC ADATPER
Features: . 3W AC/DC ADAPTER . Worldwide AC Input Voltage 100-240V . Output Voltage Range: 6V . Output Current Range: 500mA . Ripple and Noise: 1% Surge: 3KV . Short-Circuit/Overvoltage/Overcurrent Protection . Warranty: 2 years
INPUT
Input Voltage	85-264VAC
Input Frequency	47-60Hz
Input Current	0.3A Max at 110VAC
Inrush Current	40A Max at 230VAC
Earth Leakage Current	Class II
No Load Input Power	<0.3W
OUTPUT
Output Voltage	6V 500mA
Start Up Delay	1.3s Max
Start Up Rise Time	15ms Typical
Hold Up Time	10ms Min at full load 115VAC
Line Regulation	+/-1% Max
Load Regulation	+/-5% Max
Ripple Noise	1% Max
Overvoltage Protection	150% Of Nominal Output
Overcurrent Protection	150% Of Nominal Output
Short Circuit Protection	Trip And Restart
GENERAL
Isolation	3000VAC Input To Output
MTBF	50KHrs To MIL-HDBK-217F At 25OC
Operation Temperature	-10 To + 70 OC
Cooling	Natural Convection
Operating Humidity	5% To 90% RH,Non-Condensing
Storage Temperature	-40 To +90 OC
Shock	30g,Half Sine,6 Axes
Vibration	5-50Hz,Accelerated 7.35m/s
Altitude	3000m
EMC & SAFETY
Emissions	EN55022
Harmonic Currents	EN61000-3-2,Class A
Voltage Flicker	EN61000-3-3
ESD Immunity	EN61000-4-2
Radiated Immunity	EN61000-4-3
EFT/Burst	EN61000-4-4
Surge	EN61000-4-5
Conducted Immunity	EN61000-4-6
Magnetic Field	EN61000-4-8
Dips Interruptions	EN61000-4-11
Dimensions & Weight
Dimensions	2.17 in x 0.79 in x 2.95 in ( 5.5cm x 2cm x 7.5cm )
Box Size / PCS	4.72 in x 2.76 in x 2.09 in (12cm x 7cm x 5.3cm)
Carton Size / CTN	19.69 in x 15.16 in x 11.22 in (50cm x 38.5cm x 28.5cm)
Package	BOX+CARTON 100PCS/CTN
Packing List
1 x Paper Box 1 x Adapter
Terms of payment
1) T/T: Internet bank, telegraphic transfer 2) Western Union 3) Paypal 4) Ali Escow 5) Irrevocable L/C draft at sight
Shipping Methods
Express/Air transportation: DHL, FEDEX,USP, EMS, TNT, ARAMES / Sea Transportation / Land Transportation
