AC plastic mixed flow inline duct fan
- 3000 Piece / Pieces per Month
- NINGBO/SHANGHAI
- T/T Credit Card PayPal
Product Details
Electric Current Type: | AC | Blade Material: | Plastic | Mounting: | Duct Fan |
Place of Origin: | Zhejiang, China | Brand Name: | FENGDA | Model Number: | GDFP100 |
Power: | 26-30W | Voltage: | 110v 220v | Air Volume: | 198-220m³/h |
Speed: | 2200-2500RPM | Certification: | CE, ROHS, UL | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
AC plastic mixed flow inline duct fan
1, Fan diameter : 100mm to 200mm.
2, The voltage :110-120V/60Hz ,220-240V/50Hz according to customer's requirements.
3,Color:Black and White
4,Operating temperture rage:-20℃~60℃
5,Long life with low energy consumption
Model | Voltage (V) | Frequency (Hz) | Current (A) | Power (W) | Speed (RPM) | Air Flow (m³/h) | Pressure (Pa) | Noise (dB) |
GDFP100 | 220-240 | 50 | 0.12 | 26 | 2200 | 198 | 156 | 31 |
110-120 | 60 | 0.26 | 30 | 2500 | 220 | 160 | 31 | |
GDFP125 | 220-240 | 50 | 0.14 | 33 | 2250 | 284 | 159 | 32 |
110-120 | 60 | 0.30 | 40 | 2500 | 310 | 165 | 32 | |
GDFP150 | 220-240 | 50 | 0.26 | 60 | 2300 | 530 | 300 | 33 |
110-120 | 60 | 0.61 | 70 | 2500 | 580 | 350 | 33 | |
GDFP200 | 220-240 | 50 | 0.40 | 130 | 2250 | 900 | 380 | 43 |
110-120 | 60 | 0.85 | 150 | 2500 | 1000 | 430 | 43 |
Model | A | B | C | øD | E | F | G | H |
GDFP100 | 295 | 170 | 80 | 96 | 204 | 111 | 103 | 60 |
GDFP125 | 295 | 170 | 80 | 122 | 204 | 111 | 103 | 60 |
GDFP150 | 295 | 194 | 80 | 148 | 230 | 126 | 122 | 60 |
GDFP200 | 307 | 203 | 100 | 197 | 240 | 138 | 138 | 75 |
FENGDA was establish in 1990,covering an area of 17,000 square meters,more than 200 employes.We professionally manufacture various fans and motors,which widely used in Ventilation,air condittion,air condition,cooling and heating industry.
We have gotten CE,UL,CCC certificates and ISO9001 Quality Management System Certification.nd our products are exporting to Europe and America,Middle East,Russia etc.
1.Warranty:1 year warranty for all products.
2.Products Quality:100% products inspection before delivery.
3.Just in time delivery: Normally,lead time is 30 days.
4.Customized Service: As we have our own molding department,customized service can be provided.
5.Prompt customers services:E-mail will be replied in 24 hours.
1. Q: Do you provide warranty for the goods?
A: Yes, we provide warranty for all the goods from us.
2. Q: Could FENGDA provide technology support?
A: We're in this field many years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.
3. Q: Does FENGDA keep goods in stock or only trading?
A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.
4. Q: Could you fill the invoice for customs as our requirement?
A: Yes, if there's any requirement for it, please tell us. We'll do it.
