Truck scale/ Track scale/ Hopper scale Load Cell/ Sensor/ Transducer
NO: H8 0.5t ~25 t
1.Capacities:0.5t to 25t.
2. High accuracy.
3. Alloy steel construction.
4. Low profile and nice exterior.
5. With OIML approval: (PTB: D09-05.20)
H8 load cells are available for manifold accurate measurement in the capacity 0.5t to 25t.
1. Alloy steel, cover welded, oil-proof, waterproof and anti-corrosion, suitable for multiform environment.
2. Single shear beam and easy for installation, it issuitable for truck scales, track scales hopper scales and other electronic weighing devices.
3. It is safety and anti-explosion product that can be used in atrocious weather and hazardous areas.
Specifications
Capacity | t | 0.5/1/2/2.5/3/5/10/15/20/25 | |||
Accuracy class |
| C2 | C3 | A5M | B10M |
Approval |
|
| OIML R60 C3 |
|
|
Maximum number of | n max | 2000 | 3000 | 5000 | 10000 |
Minimum load cell verification interval | v min | E max/ 5000 | E max /7500 | E max /15000 | E max/ 10000 |
Combined error | (%FS) | ≤± 0.030 | ≤± 0.020 | ≤± 0.026 | ≤± 0.050 |
Creep | (%FS/30min) | ≤± 0.023 | ≤± 0.016 | ≤± 0.017 | ≤± 0.040 |
Temperature effect on sensitivity | (%FS/10°C) | ≤± 0.017 | ≤± 0.011 | ≤± 0.013 | ≤± 0.040 |
Temperature effect on zero | (%FS/10°C) | ≤± 0.029 | ≤± 0.019 | ≤± 0.014 | ≤± 0.020 |
Output sensitivity | (mv/v) | 2.0±0.002 | |||
Input resistance | (Ω) | 350±3.5 | |||
Output resistance | (Ω) | 351±2 | |||
Insulation resistance | (MΩ) | ≥ 5000(50VDC) | |||
Zero balance | (%FS) | 1.5 | |||
Temperature,compensated | (°C) | -10~+40 | |||
Temperature,allowed | (°C) | -35~+65 | |||
Excitation,Recommended | (V) | 5~12(DC) | |||
Excitation,Max | (V) | 18(DC) | |||
Safe overload | (%FS) | 120 | |||
Ultimate overload | (%FS) | 150 | |||
