15ton~50ton Digital Weiging Scale Manufacturer

Specifications

Heavy Duty Crane Scale
1.56mm LED Display
2.Material: 10mm complete steel plate
3.CE, ISO
4.Manufacturer





OCS-Z 15ton~50ton Digital Weiging Scale Manufacturer



Technical Parameter

1. External accuracy:1/3000

2. Function key:  Tare, Zero, Hold, On/Off

3. Display:56mmLCD/LED

4. Body material: 10mm steel plate welding, quite sturdy and much tronger

5. Hook and shackle: galvanized, rust and corrosion resistant

6. Units: kg, lb

7. Tare Range: 100% F.S

8. Zero range: less than 4% F.S

9. Maximum reading: 100%F.S+9e

10. Safety Load: 125%F.S

12. Ambient temperature: -10°C --40°C/14F--104F

13. Battery: 6V/10 Ah rechargeable lead-acid battery, standby mode are up to around 200 hrs



Specifications



Capacity	Resolution	Minmum load(20d,d=e)
15ton	5kg	100kg
20ton	10kg	200kg
30ton	10kg	200kg
50ton	20kg	400kg



Dimension sketch



Packing detail



Model	Packing	G/W(KG)	N/W(KG)	Measurement(CBM)
OCS-Z 15T	Wooden case	91	86	0.09
OCS-Z 20T	Wooden case	91	86	0.09
OCS-Z 30T	Wooden case	180	174	0.209
OCS-Z 50T	Wooden case	205	198.5	0.331

PS: All packing are lined with foam,strong shock resistant,ensure long-journey safety





Factory outline

Lightever is an ISO9901:2008 verified company, specializing in digital scales for over 12 years, products cover counting sclae, weighing scale, bench scale, floor scale, forklift, and weighing  bridge.Besides, maintain a long-term business partner relationship with the Japan digital scale company  Shimadzu; Among other things, all of our digital scales have the CE certificate and 12 monthes warranty.
