RL30 Liquid Differential Pressure Controller.
US$ 70 - 120
MOQ: 10 Units
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
Roleen
Model Number:
RL30
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Japan
Brand Name
Roleen
Model Number
RL30
Max. Current
5A
Max. Voltage
250 Vac
Max. Working Pressure
3.0 Mpa
Specifications
Water/liquid Flow SwitchMax. Liquid Pressure150 Psig(1034 kPa)
RL30…Liquid Differential Pressure Controller.
RL30 Series Differential Pressure Controller incorporates two extremely sensitive pressure elements which directly oppose each other. A change in pressure at either element causes appropriate positioning of the switch mechanism which is then used to control supplementary equipment such as motor actuated valves..The switch mechanism provides SPDT non-snap acting (floating) action.
RL30 Series Differential Pressure Controller | |||
Materials |
Stainless steel; imported switches (German, CHERRY) |
||
Dimension |
59×47×153mm |
||
Power supply |
5amp 125/250VAC 1/4H.P. 125VAC |
||
Data |
Model |
Differential Range |
MOP |
RL30B |
0.06~0.3Mpa |
2.0Mpa |
|
RL30C |
0.2~1.2Mpa |
3.3Mpa |
|
Floating diff. Pressure |
≤ 0.03Mpa |
||
Ambient Temp. |
< 85℃ |
||
