200mm Axial Fan With External Rotor Motor

200mm Axial Fan With External Rotor Motor photo-1
200mm Axial Fan With External Rotor Motor photo-2
200mm Axial Fan With External Rotor Motor photo-3
200mm Axial Fan With External Rotor Motor photo-4
200mm Axial Fan With External Rotor Motor photo-5
200mm Axial Fan With External Rotor Motor photo-6
US$ 30 - 40 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
AC
Blade Material:
Stainless Steel
Mounting:
Other, Axial fan
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Electric Current Type AC
Blade Material Stainless Steel
Mounting Other, Axial fan
Place of Origin Zhejiang, China
Brand Name FENGDA
Model Number YWF
Power 60W
Voltage 220V or 380V
Air Volume 1326CFM
Speed 2550RPM
Certification CE, ROHS, UL
After-sales Service Provided Overseas third-party support available

200mm axial fan with external rotor motor





Product Description





200mm axial fan with external rotor motor



200mm axial fan with external rotor motor



200mm axial fan with external rotor motor200mm axial fan with external rotor motor200mm axial fan with external rotor motor

200mm axial fan with external rotor motor

Model

Voltage

    V

Frequency

   Hz

Current

    A

Input Power

  W

Speed

   RPM

Air  Flow

    m3/h

Capacitor

     uF

Noise

 dB(A)

Curve
YWF2E200 220   50  0.23   60 2550   780    2  50  1
 120   60  0.62   70 2800   910    8  51  2
YWF4E200 220   50  0.20   40 1450   540   1.5  45  3
 120   60  0.28   45 1650   650    6   46  4

200mm axial fan with external rotor motor200mm axial fan with external rotor motor



YWF series external rotor motors have two kinds ,single phase asynchronous capacitor fan motor and three phases

asynchronous fan motor.The Voltage of single phase motor is 120V,60Hz,220-240V,50/60Hz.The Voltage of three phases  motor is 380V,50Hz,or according to customer's requirements.



Fan diameter is from 200mm-900mm.



The using life is over 30000 hours.



The using ambient temperature is from -30℃~60
