Home > Products > Small scale Air separation plant > Handan air separation plant
Handan air separation plant
- 30 Set / Sets per Month
- Tianjin
- T/T
Product Details
Place of Origin: | Hebei, China | Brand Name: | DYON | Model Number: | KZO-120 |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1.Technical parameters
Oxygen output 120Nm3/h
Oxygen Purity 99.6%
Working pressure ≤1.2Mpa
Starting time ~8h
Total power 203KW
Power supply As required
Advantages of KZO-120
2.1. All unit machines are skid-mounted construction, connected by fixed-size short pipe, after testing on supplier site, delivery the plant together with all pipes and valve to User site, the User needn’t buy them by themselves, we make ensure the plant’s perfect and integrate.
2.2 The User only need prepare well the workshop, workshop ground and crane is ok, needn’t prepare other installation materials and tools.
2.3 Small volume, occupied small area, complete set of plant only occupied 54M2(18m×3m).
2.4 Complete set of plant be installed without foundation, also has following advantages: stable running, easy operation, convenient maintenance, without easy-damaged spare parts within two years.
2.5 To keep all valve’s quality, the cold-valve of Rectification column adopt the best-quality valve in Air separation Industry; the Purifier valve adopt stainless steel valve, install thermostability mat in it, ensure little wear, no cooling leak, no gas leak, long life, during the long-term running.
2.6 All unit machines adopt the advanced technology, so reduce power consumption greatly, save electricity fee.
2.7 The cooling way of plant is by air, the User needn’t make cooling water pool, save capital cost.
2.8 The installation and commissioning time is very short, it only need 5-10 days.
2.9 The pipe of Purifier, and connecting pipe between Purifier to Rectification column, used in cold-heat environment alternately, the temperature changed range from 5℃~300℃ long-term, when temperature is low, condensing-water corrode pipe, when temperature is high, make the pipe oxidation seriously. To ensure the life of connecting pipe, and safety of plant, after all pipes connected and rust cleaning,then spray thermostability anti-corrosive primer and anti-corrosive finish-paint, avoid the corrosion, ecclasis and peeling appearance of pipe and plant.
2.10 To the safety of plant running, set four-stage pipe oil-filter, ensure no oil enter into Purifier and Rectification column, for watch the oil quantity, so that change the filter core, ensure the safety of follow-up plant, all filter equip pressure-difference meter, through the display of meter, judge the degreasing effect and filter core best change time, prevent bring oil enter system after the filter core lose efficacy.
2.11 The power consumption and starting time is the question cared mostly by
every User,through many years experience, we improve the technology of complete set of plant, shorten the starting time of both heat start and cold start, gap stop 12 hours, start(cold start) within one hour only, more suit to the shortage of sale volume condition and electricity price has peak and valley condition.
We can dispatch 2-3 technicians to user's site to guide installation, adjusting & training works, period is about 15-30 days. The user is responsible for the visa, return tickets, board &lodging, medical care & local transportation. The salary is USD 100 per day personal. The user needs to prepare tools, auxiliary materials & foundation.
Handan Dyon Air Separation Plant CO.,LTD, founded in 2009, is a professional engaged in air separation plant, dissolved acetylene plant, chemical tail gas recycling equipment, food grade CO2 equipment, liquefied natural gas equipment, N2O plant design, research and development, manufacture and after-sales service as one of technological innovation-oriented enterprises. Company existing staff 56, including engineering and technical personnel 13, senior engineering personnel 6, all is for many years engaged in the field of low temperature and chemical products’s technical research and development and manufacturing personnel, in the long-term technology research and development and the production practice has accumulated rich experience.
Company to the abundant technical force as the backing, during short few years, on the basis of Skid-mounted air-cooled oxygen and nitrogen making plant, design and manufacture the domestic first set of 600Nm3/h oxygen with argon plant, the first set of 1000Nm3/h oxygen with argon plant; Made the domestic first set of 20000 tons/year of large coal bed methane gas liquefaction projects; Taken the lead in developing the domestic nylon acid fat waste water recycling project, to fill the domestic blank; Invented by cryogenic method to recycle hydrogen by-product during the manufacture of polysilicon cross-linked silicon and silicon tetrachloride technology; Invented by cryogenic method of acetyl chloride and hydrogen chloride in chloroacetic acid production exhaust gas recycling technology, and access to national patent grants.
Our main products are:
1.Air Separation Plant
20-180 Nm3/h Skid mounted oxygen and nitrogen Plant
In vitro liquefaction Plant
Liquid Plant (liquid oxygen, liquid nitrogen, liquid argon)
Large, medium and small size low pressure energy saving air separation plant with argon
Medical oxygen Plant
PSA VPSA Oxygen and nitrogen Plant
2. Dissolved acetylene Plant
3. Chemical tail gas recycling facility
4. Food-grade CO2 equipment
5. N2O plant
6. The cryogenic technology application and development
Products are exported to Chile, Trinidad and Tobago, the Philippines, Indonesia, Vietnam, Laos, myanmar, kazakhstan, tajikistan, Russia, Syria, Iraq, Nigeria, Burundi, Zimbabwe, Libya, etc more than 20 countries and regions.
Handan Dyon Air Separation Plant CO.,LTD. Based on the "quality credibility to survive, technology development and development" enterprise policy, adhering to the chuang tzu and party made use of "useless" ideas, no use is big use, constantly blaze new trails, strive to build a gas industry technology leader and pioneer, for the general customers to provide professional quality services.
Welcome customers at home and abroad to visit and negotiate! Look forward to sincere cooperation with you!
