CE RoHS Epistar 5630SMD driverless led downlight, trimless downlight
- 50000 Piece / Pieces per Month
- shenzhen China
- T/T Credit Card
- Linear Downlight
- LED Downlight
- A Anti-glare Waterproof IP65 led downlight project waterproof spots light 5w 7w 9w 12w downlight
- A Surface Mounted Led Downlight AC LED Bulb Outdoor Adjustable Led Downlight Lamp Spot Light
- Dimmable IP65 LED Down Lights (30-300W)
- Emergency IP65 LED Down Lights (30-300W)
Product Details
LED Light Source: | 5630SMD | Warranty(Years): | 3 | Input Voltage(V): | AC 100-240V 50/60 Hz |
Lamp Power(W): | 18 | Lamp Luminous Flux(lm): | 1450 | Lamp Luminous Efficiency(lm/w): | 80 |
Color Temperature(CCT): | Pure White | Working Temperature(℃): | -20, 50 | Working Lifetime(Hour): | 50000 |
Lamp Body Material: | Aluminum Alloy | IP Rating: | IP44 | Certification: | CCC, CE |
Model Number: | WK-DL-D28-12W | Place of Origin: | Guangdong, China | Brand Name: | shenzhen wellking |
Product Description
CE RoHS Epistar 5630SMD driverless led downlight, trimless downlight
Product Data
Model#: | WK-DL-D28-18W |
Product Size: | φ215*88mm |
Hole cutting size: | φ200mm |
Power Consumption: | 18W |
Input voltage: | AC 100-240V 50/60 Hz |
LED type: | 5630SMD |
Color Temperature: | CW/NW/ WW |
Lumens: | 1450 lm±10% |
CRI: | >80 |
Housing Material: | aluminum (spinning integration) |
Optical Efficiency: | 80lm/W |
Weight per pcs: | 210g |
Pcs per carton: | 30pcs |
G.W. per carton: | 10kgs |
Carton Dimension: | 520*455*520mm |
1. Eco-friendly. No UV, toxic mercury and lead contained.
2. Energy saving. High performance, low attenuation, saving electricity up to 80% compared to halogen lamp.
3. Flicker free, it is harmless to eyes.
4. Low heat generation. Safety touching.
5. Long life span. The available time can reach 50,000 hours on condition that operating under permission.
6.Flexible color choice both for the shell material & LED.
7.CE, Rohs, FCC approval.
1.Your inquiry will be replied within 24hours, except the holidays;
2. Customized design is available,OEM and ODM are welcome;
3.Deliver the goods to our customer all over the world with speed and precision.
4. 7 days of replacement period for free if any quality problem happened.
5. 2 years warranty period; very low cost for repairing
Q: Nearly all epistar led downlight review are the same exterior,how to tell quality?
A: Price and exterior.
Though LED lighting products are with same or similar exterior,due to raw material cost difference is big,poor quality are all poor heatsink exterior with poor heat dissipation.So prices are also low.
Besides,the driver exterior is also low-end with poor IC,MOS and capacitances.
Q:Does epistar led downlight review really have 50,000 hours lifespan?
A:50,000 or longer lifespan is only theroy from lab test.But due to working enviroments are different from in lab,actual lifespan is only <=30,000hours.
Q:For same power,why different suppliers with different brightness?
A:Different chips,or same chip but different brightness version.The brightness will be different.But for same chip and same brightness version,the brightness will be slight difference.But please make clear the brightness difference between LEDs and lamp fixture.
For example,12w LED downlight,the LEDs initial brightness is around 1400lm.But the true lamp fixture brightness will lose some due to cover and heat,then will be around 1000lm.But some suppliers write LEDs brightness 1400lm in datasheet to attract clients.Please be careful.
