ETS2222+ (800MHZ) HUAWEI CDMA FWP (ruim/non Ruim) Hot!!!

HUAWEI ETS 2222+ CDMA Fixed Wireless Phone / FWP / Cordless Phone with 1 Ruim card slot

CDMA FWP 800Mhz ruim/non ruim

1.supports Call ID, Call Restriction, Call Forward, Call Waiting
2.widely used in payphone
3.a computer by a RS232 cable

Features:

CDMA800M

CDMA2000 1X RTT standard
High-quality voice services (8 kbps EVRC)
Multiple supplementary services
SMS
Large-capacity phone books and call records
Alarm clock function
11 ring options for incoming calls
Green backlight display and red backlight keypad

Maximum power than: 23dBm
Maximum input power: - 25dBm
receiving sensitivity: superior 104dBm - rx
Power specifications:
AC: 90V~264V
DC: 5.0V, 0.65 A
Backup battery charge: the types, volume: NiMH: 1000mAh (optional) V600mAh 3.6
Maximum time (based on network environment) :
2 hours (battery capacity of 600 mAh)
3 hours (battery capacity of 1,000 mAh)

Maximum standby time (based on network environment) :
72 hours (battery capacity of 600 mAh)
90 hours (battery capacity of 1,000 mAh)
products dimensions (W X D X H 183mm*204mm *85mm
Weight (contain batteries) : below 700g (including battery)
LCD display: 128 * 64 matrix (optional),
Working temperature: - 10 ° ~ + 55 °c
Storage temperature: - 20 ° ~ + 70 ° c
Accessories: a charger/ a battery /antenna

Parameters

1. Air interface:  CDMA 800Mhz frequencies
2. External in interface:
   The power supply interface: POWER / DC12V
   Outside phone interface: RJ-11(PHONE)
   Outside fax interface: RJ-11 (FAX)
   The antenna interface: SMA (Male)
   The data Service interface: SERIAL PORT

 3. Power adaptor:

    Input voltage: AC90-260V / 50Hz
    Output voltage: DC12V
    Output current: 1.2 A
4. Backup battery:
    Ni-MH battery
    7.2V / 1.2A

 5. Antenna:

   Frequency Band:
   890-960 MHz / 1710-1880 MHz
   Gain: 2.5dBi
   Wave ratio: ≤1.5
   Input resistance: 50ohm.
   Polarize method: perpendicularity polarizes
6. Dimensions(L*W*H) Average 226mmX226mmX551mm(not include the antenna)
7. Weight: 1200g (include the antenna, battery, power adaptor.)

Features:

1) adopts the high CDMA2000 1x 5105 chipsets, more perfect compatibility, avoided completely base on base of don't match. More fluent, high-speed internal operation, make the function more powerful, phone more stable performance, and support high-speed Internet connections, is based on CDMA2000 1x 3G network compatibility is preferred.

2) signal, the ability to accept for wireless fixed telephone customizing templates of integration, more professional, in addition to the antenna, made in wireless signals in unit interior near 0 per a wireless phone, before they are strict inspection, measuring the end that one line.any quality unit of signal intensity 104DB reach above all, in the region has a bad signal is more perfect.

3), all of the internal highly integrated function in a conventional only finish, and integrated circuit technology synchronization, leading countries guarantee the performance is stable and reliable, and the boards and durability, maximum guarantee the product quality, more perfectly suitable for various USES environmental needs.

4) support for the English, operation menu with a friendly interface, easy to use, and more support CDMA short message service.

5) strict testing procedures: each machine factory is to pass up the test procedure, and five times that of each stable and reliable quality
