Disk Mill FFC Series--FFC-15, FFC-23, FFC-37, FFC-45

IKLIM HARDWARE & MACHINERY SDN. BHD.
Disk Mill FFC Series--FFC-15, FFC-23, FFC-37, FFC-45 thumbnail-1
Disk Mill FFC Series--FFC-15, FFC-23, FFC-37, FFC-45 photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model Number:
FFC-15, FFC-23, FFC-37, FFC-45
Weight:
18KG, 65KG, 158KG, 224KG
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Model Number FFC-15, FFC-23, FFC-37, FFC-45
Weight 18KG, 65KG, 158KG, 224KG

Specifications

1. Simple and easy operation system.

ModelFFC-15FFC-23FFC-37FFC-45
Rotational speed of main shaft9000rpm5800rpm3600rpm3000rpm
Outer dia. of the rotor(including flat tooth)150mm230mm370mm450mm
Number of oblate gears of the rotator3pc3pc4pc5pc
Number of knuckle gears of the rotator3pc3pc8pc12pc
Circles of square gears of the gear wheel2 circles2 circles 2 circles2 circles
Pitch between the oblate gear& screen9mm9mm16.5mm16.5mm
Sieve size(screen strap)(MM)0.6, 1.20.6, 1.20.6, 1.20.6, 1.2 3.5
Dimension (MM)565mm*305mm*610mm800mm*500mm*1000mm1050mm*680mm*1325mm1150mm*755mm*1425mm
Weight (excluding motor)18 Kilogram (KG)65 Kilogram (KG)158 Kilogram (KG)224 Kilogram (KG)
Motor Power1.5hp 240V2hp240V , 3hp240V , 4hp415V10hp 415V15hp 415V
Motor Speed3000rpm3000rpm1500rpm1500rpm
