Kodak Achieve T800 platesetter thermal ctp machine
General Specifications
Technology |
830 nm Thermal CTP machine,Semi-automatic,External drum |
Load /unload systems |
Standard: Semi auto load plate and unload Auto unload: Semi auto load , auto unload to Processor or Stacker; automatic rotary plate Auto load: Auto load and unload - without the backing plate 40pcs (0.30mm) |
Media Support |
Kodak Achive EM thermal plates, Kodak Electra XD Thermal Plate and Kodak Sonora XP Chemical-Free computer to plate |
Performance Specifications
Capacity |
Standard and auto unload |
Auto load : |
||
2400 dpi 1, 2, Max. Size:1030 x 838 mm |
S-speed = 16 plates / hour F-speed = 22 plates / hour |
S-speed = 16 plates / hour F-speed = 22 plates / hour |
||
Accuracy |
± 20 μm (± 0.8 mil), two different plates |
|||
Registration accuracy |
± 25 μm (± 1.0 mil) , Between Imaging area and plate edge |
|||
Workflow link up |
Kodak Prinergy Evo Workflow, Kodak Prinergy Workflow, can link up with third-party workflow systems. Standard machine includes XPO TIFFdownloader software,which can be linked up with most third-party workflow systems |
|||
Imaging Specifications | ||||
Resolutions |
2400 dpi (94.4 dpmm) or 1200 dpi (47.2 dpmm) |
|||
plus screening |
300 lpi ,The maximum number of plus screening Alternative 36 μm Kodak STACCATO screening |
|||
Max. size: |
Standard : 838 x 1,143 mm |
Auto unload : 838 x 1,118 mm |
Auto load : 838 x 1,118 mm |
|
Min. size : |
267 x 215 mm |
383 x 270 mm Manual unload : 267 x 215 mm |
383 x 270 mm Manula load and unload: 305 x 215 mm |
|
Max. Imaging area |
827.9 x 1,143 mm |
827.9 x 1,118 mm |
827.9 x 1,118 mm |
|
Device size | ||||
Size (H x W x D) |
Standard : 160 x 200 x 120 cm |
Auto unload : 210 x 200 x 180 cm |
Auto load : 210 x 200 x 180 cm |
|
Net weight |
650 kg |
744 kg |
750 kg |
|
1 imaging speed and production capacity depends on the sensitivity of the medium. All media sensitivity values are 120mJ / cm²
2 KODAK workflow solutions tested. For additional information about the test conditions, please consult Kodak representative.
3 Standard plate thickness of 0.15-0.3 mm.
This CTP is a Class 1 laser products, fully comply with EN60825-1 and
US Federal 21 CFR 1040.10 - CDRH regulations.
Gauss Imaging technology Kodak TH5 technology
Violet,thermal,CtCP |
Thermal (25W ) |
24-64 chanel |
128 channel |
Color stability -low |
Color stability - Medium to high |
Exposure uniformity-Low |
Exposure uniformity-High
|
Delivery:
1. CTP machine :30 days
2. CTP plates:10-25 days
Installation and training:
1.Welcome to learn the operation and maintenance in our factory free of charge.
2.We can send technican to oversea to help you with installation and training.
But 2 way tickets and accomodation will be charge by the buyer.
Be free to Contact with us,will be replyed in 12 Hours !
Attn: Mr.Ken Wan Mobile:+86 13590991044
Skype: 1492073753_1 Whats App: 0086-13590991044
Wechat: 13590991044 QQ: 2876562724
