Amsky Offset Printing Machine Thermal Cpt Machine

Name: Amsky Offset Printing Machine Thermal Cpt Machine
Brand: Amsky
SKU: 133027509
Availability: InStock

Guangzhou Colorte Printing Company Limited

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Other, Plate Exposure, Plate setter

Automatic Grade:

Automatic

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Plate Exposure, Plate setter

Automatic Grade Automatic

Place of Origin Guangdong, China

Brand Name Amsky

Model Number Aurora 800 series

Voltage 200V-240V, 200V-240V

Power(W) Max power(Peak value):4KW, 4kw

Dimension(L*W*H) 2,010X1,410X1,200mm(WXDXH), 2,010*1,410*1200mm

Weight 1200 kgs

Certification GB/T19001-2000 Idt ISO9001:2000 Standard

Warranty 2 Years

After-sales Service Provided Engineers available to service machinery overseas

Amsky Thermal CTP machine Aurora 800 series

Product Description

Amsky Aurora 800 Series Technical Specifications

Mode	T864
Exposing Method	External Drum
Imaging System	64-channel
	Discrete 830nm laser
Output Speed	28 plates/hour
	1030×800mm 2,400dpi
Plate Size	Max.1130×920mm,Min. 510×400mm
Exposing Size	Max.1130×904mm
Media Type	Thermal plate	Thermal plate
Plate Thickness	0.15mm~0.3mm
Resolutions	2,400dpi
Repeatablity	±5μm(Continuous exposure over four times on the same plate with a temperature of 23°C and 60% RH)
Interface	USB2.0/USB3.0(Recommended option is USB2.0)
Plate Loading	Alternative autoload system
Net Weight	1,200KG
Device Size	2,010×1,410×1200mm(W×D×H)
Power supply	Single phase:200V-240V; Max power(Peak value):4KW
Environment	Recommended temperature: 21-25℃ Allowable temperature: 18-26℃ Humidity: <70%
