Dispensing Robot/Glue Dispenser Machine
YSATM-3L Features:
1 English keyboard operation.
2 Function: drawing point, line, surface, arc, circle, irregular curve continuous complement and triaxial linkage. 3 The software has the area display, translation rotating operation functions.
4 Can set glue size, glue speed, dispensing time, stopping glue time. Stable glue exudation without glue leaking and dripping.
5 According to the production process, work platform can be installed with positioning PIN, glue guns, baseboard heating temperature controlling device.
6 Applied to fluid dispensing, e.g.:UV glue, AB glue, EPOXY(black glue), white glue, EMI conductive glue, silicon, epoxy resin, instant glue, silver glue, red glue, paste, thermal grease, welding control paste, transparent paint, screw fixative ......
7 Applicable objects: mobile phones, computer case, CD-ROM driver, printer, ink folder, PCB board, LCD, LED,DVD, digital camera, switches, connectors, relays, radiators, semiconductors, clocks, toys and medical appparutus.
Specification | ||||
Model |
YS-220D |
YS-330D |
YS-440D |
YS-550D |
Working Area |
200*200*50mm |
300*300*100mm |
400*400*100mm |
500*500*150mm |
Max. Speed |
500mm/sec |
|||
Resolutio |
0.02mm |
|||
Repeatability |
±0.02mm |
|||
Operator system |
LCD panel/keyboard |
|||
Drive Mode |
Micro stepping motor/belt |
|||
Power |
AC 220V 50-60 Hz 0.8KW |
|||
Size |
380*370*500mm |
480*500*600mm |
580*600*600mm |
640*700*720mm |
Weight |
20KG |
30KG |
40KG |
50KG |
|
Configurations
| |||
Name |
Quantity |
Unit |
Remarks |
Motor |
3 |
set |
Micro stepping motor |
High precision dispensing valve |
1 |
pc |
Optional |
Movement vontroller |
1 |
set |
|
Automatic dispenser software |
1 |
set |
Automatic independent R&D |
Dispensing controller |
1 |
set |
SMC/MAC |
