Stainless Steel Liquid Mixing Tank With Emulsifier

Stainless Steel Liquid Mixing Tank With Emulsifier photo-1
Stainless Steel Liquid Mixing Tank With Emulsifier photo-2
Stainless Steel Liquid Mixing Tank With Emulsifier photo-3
Stainless Steel Liquid Mixing Tank With Emulsifier photo-4
Stainless Steel Liquid Mixing Tank With Emulsifier photo-5
Stainless Steel Liquid Mixing Tank With Emulsifier photo-6
US$ 5,000 - 50,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Homogenizer
Product Type:
Other, pharmaceutical, agricultural, veterinary, food, chemical and bio field
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Mixer Type Homogenizer
Product Type Other, pharmaceutical, agricultural, veterinary, food, chemical and bio field
Application Liquid
Additional Capabilities Other, temp., level, weight display&record, alarm, SIP, explosion-proof, etc.
Place of Origin Shanghai, China
Brand Name SHANGHAI RITAI
Model Number RTYD
Max. Loading Capacity 20000L
Voltage 380V or others
Power(W) 0.55KW~45KW
Dimension(L*W*H) N/A
Certification ASME, PED 97/23/EC, NB, GB, ISO 9001:2008
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Product Description



Name:  stainless steel liquid mixing tank with emulsifier



Technical parameters of stainless steel liquid mixing tank with emulsifier

1.Material adopts SS316L or 304,

2. Surface finish: inside surface roughness is Ra0.28~0.4μm by mechanical polish or electropolish, outside surface roughness is Ra0.6-0.8μm by satin finish..

4. working pressure can be normal pressure or with pressure. if with pressure, please let us know the working and design pressure inside tank and inside jacket.

5. can be single layer, or with jacket or insualation. we make according to client detail requirment.
6.Components: vent filter, manhole, cleaning ball, liquid level gauge, and control system or according to clients specific requirement.
7.Specification: 5L-20000L.

8. normal pressure according to JB7431.

To make pressure vessels according to ASME VIII DIV1, PED 97/23/EC, GB150-2011 (it depends on client requirement with different cost.)


Packaging & Shipping



Packaging of stainless steel liquid mixing tank with emulsifier: wooden case or iron rack

Shipping of stainless steel liquid mixing tank with emulsifier: by sea

stainless steel liquid mixing tank with emulsifier


Our Services



We offer design, customization, manufacture, installation, and maintenance services, etc.

stainless steel liquid mixing tank with emulsifierstainless steel liquid mixing tank with emulsifierstainless steel liquid mixing tank with emulsifier


Company Information



Shanghai Ritai Medicine Equipment Project Co., Ltd. mainly specializes in innovation and development of sanitary stainless steel pressure vessels, atmospheric pressure vessels, fermenters, valves and piping system which are widely used in the following fields, such as pharmacy, biology, chemistry, food and drinks industry.

Shanghai Ritai is qualified to design and manufacture pressure vessels with the certificates of ASME, PED 97/23/EC, NB, and ISO 9001:2008.

stainless steel liquid mixing tank with emulsifierstainless steel liquid mixing tank with emulsifierstainless steel liquid mixing tank with emulsifierstainless steel liquid mixing tank with emulsifier

stainless steel liquid mixing tank with emulsifierstainless steel liquid mixing tank with emulsifier

stainless steel liquid mixing tank with emulsifierstainless steel liquid mixing tank with emulsifier
