HK-21929A Automatic Tag Closed cup flash point apparatus

 This apparatus is used for determining flash point, by Tag closed tester, of liquids with a viscosity of below 45 SUS at 100F (37.8 C) and a flash point below 200 F (93C) except cut-back asphalts and those liquids which tend to form a surface film under test conditions.

Overview

The apparatus is product of years of manufacturing experience for automatic flash point tester with advanced technology, is one of the latest type of automatic flash point tester with better functions and new mould.

The apparatus consists of control unit and measurement unit; one control unit can control two measurement units making the test at the same time.

Technical Parameters

(1) Standard: ASTM D56

(2) Flash point measuring range: room temperature to 120℃( with D60 cooler it can test -50℃ lowest)

(3) Temperature setting range: 0 ~ 300℃

(4) Display: large touch LCD

(5) Thermodetector: Platinum resistor

(6) Flash point detector: a. CRC high sensitivity thermocouple (used for closed-cup flash point);

                                            b. high sensitivity ion detection ring (used for open cup flash point).

(7) Process control: microcomputer

(8) Heater: electric heaterAC 220V 0.4KW/group

(9) Cooling method: forced cooling

(10) Test flame: liquidation fuel gas

(11) Printer: MP-D40-8 type needle printer

(12) Rated voltage: AC 220V,50~60Hz,0.8kw

(13) Weight: about 20kg

Standard Accessorias:

Sample cup

Fan cover

Fuse

Operation instruction

Socket heat wrench

Burning torch

The longer connection line can be another purchase
