1.6KW Gasoline Inverter Generator - Tiger Factory

Specifications

FUEL CONSUMPTION LOWER ,  NOISE QUIETER , USE FOR SAFER , WEIGHT LIGHTER – THE MOST SMARTEST OF GENERATORS

Designed for better life!!!

•Advanced Inverter Technology Provides Reliable Power, Ideal for sensitive equipment computers, TV etc.

•It’s durable , lightweight, compact design with built-in handle offers portable power for the outdoors , An emergency,

Construction , the home, Events ,Heating and Cooling.

•Lightweight and compact up to 40% lighter than a standard generator of equal watts .Built-in-handle-move with minimal effort.

•Super Quiet and campground friendly full enclosure drastically reduces noise.

•Operation high throttle - for large loads or battery charging immediately,

Eco throttle helps to reduce fuel consumption, operating noise and exhaust emissions level.

•Electronic Overload protection circuit breaker protected.
•Shuts the engine down if oil reaches an unsafe operating level and Prevent engine damage from overheating due to lack of oil.

•At-a-glance status Lights LED lights on the control panel indicate system status.

IN1800 portable digital inverter generator :

Model: IN1800.

Name: gasoline portable inverter generator

Engine

Engine type : 4-stroke , Overhead Valve , Single Cylinder .

Displacement : 99.3cc

Bore X stroke : φ58mmx37.6mm

Fuel type : UNLEADED GASOLINE #93

Air intake: Natural Aspiration

Start system: manual start

Compression ration : 10:1

Engine speed : 3000rpm ~ 4500rpm .

Nominal Current: 7A

Cooling system : Forced air .

Ignition system : Full transistor

Oil Capacity : 0.5L

Fuel tank capacity : 3L

Fuel consumption: 0.91L/H.

Spark plug: A7RTC

Noise Level (ISO 8528-10 ): 68dB(A )

Active continuous power:1600W@3800~4300rpm

Maximum power: 1800W@4000~4500rpm

Voltage regulation system: Closed Cycle Control

Protective switch: Electronic Overload Protection

Alternator Type: Permanent Magnet Alternator

Typ of protection: CLASS F (IP23)

Generator

AC Output :

Rated Voltage ( V):         220/230/240                   110/120

Rated Frequency (Hz):     50                                  60

Rated output (VA ):         1600                                1600

Max Output (VA ) :          1800                                1800

Dimensions (LXWXH): 530mm  x285mm x450mm

Dimensions packing(LXWXH): 560mm X301mm X 478mm

Dry Weight : 21.5KGS .

Weight incl. packing: 23.5KGS

Qty in 20ft container: 360PCS.

Available accessories

Convential tool-kit(spark wrench, spanner, manual )

Double-head Screwdriver

Spark plug socket spanner

8-10 socket spanner

Certificate :

CE-Declaration of conformity: GB/1067/1361/08 ISSUE 1

EPA: STP-NRSI-08-01

CARB: EXECUTIVE ORDER U-U166-0001/0002

It's good for outdoor applicaces such as power tools , lights , radio .

Computer friendly sine wave alternator with low thd ouput suitable for sensitive electronics .

Safe to use on all your electronic appliances , equipment , power tools .
