Specifications
1.ISO 9001:20082.Minimum Order Quantity: 1 Set/SetsTrial Order
3.Packaging Details: standard wooden case package
Detailed Product Description
This cutting machine is
economical,easy-handle,
hi-speed cutting,
safe and convenient
with low failure rate.
JIAYU-2C/27 Following hydraulic Swing Arm Die Cutting Machine
Usage and characteristics
1. The machine is applicable for cutting on one layer or layers of leather, plastic, paperboard and fabric etc. with die cutter. It is the ideal cutting equipment for such industries as shoemaking, luggage, garment, automobile, art ware, packaging and electronic industry etc.
2. There are two types of cutting for selection. The first type is small pressure stepless regulation. The second type is that the cutting adopts intelligent pressure feedback design function without setting of cutting point. The height of die cutter has no influence on the cutting and ideal cutting effect can be obtained from each cutting point.
3. Through double oil way static pressure supporting lubricating system, the vertical column makes the manual operation be easy, flexible and worry-saving.
4. The main fittings adopt high quality imported assemblies, which have characteristics such as reliable quality, low noise, high efficiency and energy saving.
Main technical parameters
Maximum cutting force |
27Tons |
|
Distance from upper pressing board to worktable |
0-85mm |
Size of the upper pressing boardCutting area |
500×500mm(swing arm) 1000×500mm(under the table) |
Main motor power |
1.1Kw |
Electric Supply Voltage |
3x440/400/380/220/200V ,50/60 Hz |
Total weightapproximate |
780kg |
Remark:We can make the machine according to your specifical order ,for example the color,the motor information ,the working table etc.
