Clean Room Air Shower For Pharmaceutical
AS series air shower
Characteristics:
This is a kind of local purifying equipment, fixed on the partition between clean room and unclean room. It is used for shower and removing dust when personnel or objects entering into clean area. Effectively reduce dust source from entering into clean area after used, and keep clean area in normal working state. Shower way: single-side shower, double-side shower, three-side shower, top shower
Main characters:
4.Modularized design,more convenient for transport and assembling.
5.Shower time is adjustable from 0 to 99 seconds.
6.Equipped with pre-filter and deep-filter system.
7.Wind speed of nozzle port can reach 25m/s. it can reach 18m/s when blowing on human body.
8.EVA sealing material makes great sealing performance.
9.We can customize the shower room body material and dimension according to different customer requirements.
Parameter:
Parameter/model |
As-800-1/1 |
AS-800-2/1 |
AS-800-3/I |
Filter efficiency |
≥99.99%@0.3μm |
||
Spraying wind speed |
≥25 |
||
Shower time |
0-99 adjustable |
||
Number of nozzles |
12 pieces |
16 pieces |
18 pieces |
Dimension of shower area |
1500x900x2000 |
1500x1200x2000 |
1500x1900x2000 |
Overall dimension |
2000x1000x2150 |
2000x1300x2150 |
2000x2000x2250 |
Chassis |
Stainless steel plate |
||
Power supply |
AC, 3N, 380V ±10%, 50Hz±2Hz |
||
Rated power consumption (W) |
1500 |
2000 |
3000 |
Weight (kg) |
500 |
700 |
1000 |
Specification and number of low effective filter (mm) |
650x400x15x2 piece |
||
Specification and number of high effective filter (mm) |
610x610x69x2 piece |
760x610x69x2 piece |
915x610x69x2 piece |
Material About Air Shower:
Cabinet Material (Optional):
1, Full cold-rolled steel with powder coating.
2, Internal stainless stell,external with cold-rolled steel.
3, Full Stainless Steel.
Door Material(Optional):
1, Cold-rolled steel with powder coating.
2, Stainless Steel.
Chassis: Stainless Steel.
1.infrared ray automatic movable door.
2.ULPA highl efficient filter.
3.No sill design,convenient for vessels to come in.
4.yellow fluorescent light,ultraviolet sterilization light,emergency stop switch.
We Also Provided:
1.The Air Shower Room Specification And Material Request.
2.UGP-FLS.
3.Pass Box Specification And Material,Technical Request.
4.Clean Bench.
5.Fan Filter Units.
6.FFU Specification And Request.
