AVF Series CUP/Yogurt Liquid Filling Machine Parts
US$ 10,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Medical, Other, Food, Medical, filling machine parts
Packaging Type:
Bottles, Other, Bottles, filling machine parts
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB NINGBO OR SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Aluminum Laminated Stand Up PouchUS$ 0.08 - 1MOQ: 10 Pieces -
Aluminum Laminated Zip PouchUS$ 0.08 - 1MOQ: 10 Pieces
-
Pharmacetical Use Tropicalized Blister FoilUS$ 5 - 8MOQ: 100 Kilograms
-
Pharmacetical Use Tropicalized Blister FilmUS$ 5 - 8MOQ: 100 Kilograms
-
Pharmacetical Use Aluminum Blister FoilUS$ 5 - 8MOQ: 100 Kilograms
Condition
New
Application
Food, Medical, Other, Food, Medical, filling machine parts
Packaging Type
Bottles, Other, Bottles, filling machine parts
Packaging Material
Glass, Plastic, Other, Glass, Plastic, filling machine parts
Automatic Grade
Automatic
Driven Type
Electric
Voltage
220V 50/60Hz
Power
0.75KW/1.2KW/2.2KW
Place of Origin
Zhejiang, China
Brand Name
LTPM
Model Number
AVF Series Automatic Sauce Filling Machine
Dimension(L*W*H)
See product details
Weight
550KG/900KG/1150KG/1500KG/1750KG
Certification
CE, GMP, SGS, BV
After-sales Service Provided
Engineers available to service machinery overseas
AVF Series CUP/Yogurt liquid filling machine parts
Quick Details:
Capacity: 30-120bottle/minute
Filling Volume: 20-5000ml, 20-500ml
Filling Accurate: 20-1000ml:≤±1% 1000-5000ml:≤±0.5%
Filling Nozzle: 4/6/8/12/16 nozzles
Description:
AVF automatic sauce filling machine is designed by referring to the same kind of foreign filling machines with extra functions increased The product is simple and convenient in operation,error correction,machine cleaning and maintenance.widely used for filling various kinds of viscosity liquid products in the industries of,foodstuffs,pharmaceutics etc.
Application:
Different kinds of viscosity liquid, sauce, kechup, etc.
Specification:
| ITEMS | AVF-4 | AVF-6 | AVF-8 | AVF-12 | AVF-16 |
| Filling nozzles | 4 | 6 | 8 | 12 | 16 |
| Filling range | 20-5000ml | 20-500ml | |||
| Ideal filling range | 20-100ml/50-250ml/100-500ml/200-1000ml/500-2500ml/1000-5000ml | ||||
| Filling speed(100ml)bpm | 30-40 | 40-60 | 60-70 | 70-100 | 90-120 |
| Filling precision | 20-1000ml:≤±1% 1000-5000ml:≤±0.5% | ||||
| Air pressure range | 0.4-0.6MPa | ||||
| Air consumption | 10m³/h | 15m³/h | 20m³/h | 30m³/h | 40m³/h |
| Power supply | 220V 50/60Hz | ||||
| Power consumption | 0.75Kw | 0.75Kw | 1.2Kw | 2.2Kw | 2.2Kw |
| Single machine noise | ≤50dB | ||||
| Net weight | 550Kg | 900Kg | 1150Kg | 1500Kg | 1750Kg |
| Overall dimension(mm) | 1300*1200*1800 | 1600*1200*1800 | 1900*1200*1800 | 2300*1200*1800 | 2600*1200*1800 |
Comptitive Advantage
- Adopt piston pump to fill high precision, large range of adjusting dosage.
- It allows to adjustment of filling column for all filling pumps at the same time, also for minor adjustment of each filling pump to achieve fill high volume accuracy.
- This pump system don't absorb the material, good chemical stability.
- Stainless steel rotary valve to fit to various kinds of viscosity product.
- Auto shut on/off filling nozzles, avoid leaking and drawing.
- Header liquid hopper, auto level sensor control product supply.
- Frequency conversion control speed, auto count output, no bottle no fill.
- The whole machine is designed according to requirements of GMP.
