7" Touch Screen LCD advertising shelf player with bar code reader
The New Stopper 7" B070A
A true liberating battery-powered device that enhances brand image and increase product sales
Push Button Activation
With a blinking button, customers are intrigued to press the button and the advertising message are 100% surely delivered.
Brand Your Display Stick A Simple Rigid Board
Just stick a simple 4C Euroscale printed carton rigid board, you can turn our B070A into an eye-catching display with vivid graphic and brand image. We help our clients to design all shapes of rigid board.
Cable Free 6 C-cell Battery Powered
Powered by 6 C-cell battery and with up to 2,160 times activations of a 15 second movie, no electrical cable is required for this battery-powered display. The retailers can place it anywhere in the retail shops without concern for electricity supply.
DC 9-12V Power Input Optional Power Adapter
For retailers in need of continuous power supply, we have the solution. Take out the battery box from the device, and the retailers can connect the device with a normal DC power adapter for continuous power supply.
Adjustable And Secure Shelf Mounting Solution
Each retail shop has its own types of shelves. We’ve taken those differences into consideration and developed a unique adjustable and secure mounting system with a lifting range of 48MM. Adding our anti-thef cable system, the retailers can be rest assured that the device would be safely and strongly mounted on the shelf.
Selectable Playback Mode
There are 2 playback mode (M1,M2) selectable. Under M1 mode, the device will maintain in stand-by mode with button blinking until the button is pushed and advertising video clips or image slideshows will be displayed for one-time from SD card; Under M2 mode, while the advertising video clips or image slideshow plays in a continuous loop, when customers push the button, a second group of videos or slideshow will be activated.
SD Card Storage And Playback
We do not use built-in flash memory, because flash memory has a failure rate. We use changeable SD card (with a cover for protection), so that not only the retailers can choose different memory size, but also the retailers can change the SD card if the card fails after certain time of use.
Direct USB Acess For Auto Content Update
By simply inserting a USB key into the device, the media files in the device can be updated automatically. The retailers do not have to open the SD card cover.With a secure file required in the USB key, we are sure that only authorized person is able to change the contents in the device.
Tech Spec
| POPSHELF-TS-BCR Series | POPSHELF-TS-BCR features interactive touch screen media player with built-in bar code reader. The application is the use of touch screen or bar code to select video tracks. | ||||||
| Models | S070A-TS-BCR | ||||||
| Cabinet | ABS housing | ABS Cabinet, available in stardard black and silver color; aslo availabel in customized color | |||||
| Acrylic sheet | Acrylic sheet on front for protection, available with customized logo printing | ||||||
| LCD Specifications | LCD Panel Size | 7" Digital | |||||
| Panel Brand | Grade A and brand new panel | ||||||
| Screen Ratio | 16:9 | ||||||
| Brightness | 250cd/m2 | ||||||
| Resolution | 800*480 | ||||||
| Viewing angle | 70/70/50/70 | ||||||
| Integrated speakers | 1W*2 | ||||||
| Power consumption | 15W | ||||||
| Power | DC 12V, 1.5A | ||||||
| Touch Panel Spec | Type | 4 wire resistive | |||||
| Surface Hardness | 3H | ||||||
| Operation Pressure | 15-70g | ||||||
| Life time | >1,000,000 times | ||||||
| Optical Clarity | 80%↑ | ||||||
| Storage Tempeature | (-20∼70) | ||||||
| Operation Tempeature | (-10∼60) | ||||||
| Random Touch Media Play Function | Support media formats | JPG, VCD,DVD,MP3, MPG4, DIVIX | |||||
| Storage media | CF card with lock protection | ||||||
| Download media | USB (Auto Copy and delete function from USB to CF card) | ||||||
| Plug-and-play | Plug-and-Play / No windows OS / Wide viewing angle TFT LCD for indoor communication | ||||||
| Playback mode | When power on, there is a demo video in loop(optional feature);Touch to playback the corresponding media files; after playback finishes, go to previous page; after 60s without touch, go to the main page; After 90s without touch the main page, playback the demo video file in loop | ||||||
| Random Multi-layer Touch | No limit of layers; Max 99 touch areas in each layer; Easy to define touch areas by coordinates | ||||||
| Motion Sensor Function | Optional motion sensor detector controls the audio/video track,to ensure that sound/video only plays when people are near | ||||||
| Bar Code Reader Functions | Hands-free, omnidirectional bar code scanner | ||||||
| Metrologic QuantumE Scan engine | |||||||
| Decoding of all standard 1D, RSS-14, RSS limited and Expanded RSS bar codes | |||||||
| 7 Beep Tones | |||||||
| Use bar code to select video tracks | |||||||
| Fixation | VESA | 75*75mm | |||||
| Packing | Accessories | Power cable*1pcs, user manual*1pcs | |||||
| Screen Dimension(mm) | 221.6*201.6*60mm | ||||||
| Net Weight(kgs) | 0.905kg | ||||||
