NJP-3200 Fully Automatic Filler
NJP-3200C adopt PLC control system, human-machine interface, when running malfunction or lack of stuff, automatic alarm, malfunction display, automatic dismiss alarm. And with functions of password setup, touching screen display, automatic parameter setup, data printing, reset, etc.
The jump-start axed, cam and other main damageable parts all adopt imported materials. And the machine is suitable for Powder, Granular and Pellet filling, one hour for 192,000capsules, special for Capsule size from00# to 5#.
1.It has been improved the inner design turret,and imports beeline bearings for each machine from Japan directly, so that it can be sure alonger usage-life and precision of machine.
2.The working station cam runs under the goodlubricating condition, and maintains the inner lubrication of cam slot to afull extent, increasing the pressure pulverization oil pump, thus extends theoperation life of the spare parts.
3.It adopts enlarged Cam, LTPM CHINA has become the one who matches the cam of RU100 to Ru83, while it enhances thestability of the machines and extends the life of the machines to a greatextent.
4.It is controlled by the computer, has astepless timing with the frequency-conversion, the numeral showing makes aneasy operation and clear appearance.
5.Adopt Plane Spring for filling powder, thistype spring can afford TWO BILLION TIMES Pressing, but never changed overalldimension. So it makes the Weight of Powder filling in an accuracy number.
6.Automatic Capsule Switch operated by TouchScreen avoid Dangerous Accident happens when open the switch by hand into theworking station.
7.Our quality machine use Tanshing Cam box, inautomatic capsule filling machine area Honest Business is the most important,Because Customers can’t see the mechanical parts inside. So our company canpromise we use the real type but never “labeling type”.
8.Add the extra function of capsule controlswitch. (Control the capsule outside of the machine; it is more safely andquickly). Add the click-moving control system, makesan easier operation and clearness.
Model: |
NJP-3200 |
Capacity: |
3200capsules/minute |
Machine suitable for: |
capsule Size #00 to 5 |
Power supply: |
380v 50Hz three phase (it can be changed depend on your requirement) |
Power consume: |
8kw |
Quantity of mould bores: |
24pcs |
Noise standard: |
smaller than 75dB(A) |
Weight: |
1800kgs |
Overall dimension: |
1375×1345×2000 mm |
1. we have seven technicians who gets passport ready to travel all over world to offer service to you.
2. We have 24hours hot line for Technical Support.
3. We get 18hours internet line for technical support.
4. Video camera in workshop to help you adjust and solve machine problem in working situation.
5. We have Technical Support in below Foreign Cities:
California (commission worker), Manila and Davao (Distributor), Lima (Agent), Ho Chi Ming and Hanoi (Agent), Dhaka (Agent), Lahore (Distributor)
