Specifications
1)simple & flexible to operate2)running stable,saving power
3)vertical heads & slanting head
4)High-Grade part
5)High speep
PG-4 MODEL
| PG Leak Detector High-Grade parts | ||||||||
| Spare part name | Brand | Remark | ||||||
| 1 | PLC | German Siemens | ||||||
| 2 | Expanding Module | German Siemens | ||||||
| 3 | Digital moudle | German Siemens | ||||||
| 4 | Touchscreen | Colourful touch screen from TaiWan | ||||||
| 5 | Pressure sensor | USA | Special type | |||||
| 6 | Electronic moudle | Italy | ||||||
| 7 | Precision air board | Italy | ||||||
| 8 | Precision leak detection valve | Japan SMC | ||||||
| 9 | Precision air blowing valve | Japan SMC | ||||||
| 10 | Photo sensor | Original OPTEX from Japan | ||||||
| 11 | inverter | Original Shneider from Germany | ||||||
| 12 | precision Pressure adjusting valve | Original NORGREN from England | ||||||
Compact structure, simple and flexible to operate, running stably and
energy-saving In accordance with different requirements, the testing heads installation can be vertical and oblique to meet the needs of different products.
production speed: 1200-1800 bottles/hour
lifting platform adjustment capacity: 910mm-1200mm
Box size: L1.5*0.77*1.7M
Especially designed for high-volume bottles by Adopting reduction voltage
circuit design to meet the needs of different requirements.
Precise air charging container leak detector
PG bottle/pot leak detection equipment widely applies to industries in food,medicine, medical instrument, chemical, the gas spray pot,plastic container and the automobile, motorcycle parts.ultrasonic welding production line examination is also the important equipment by Which the quality safty supervision department use for spot-check and leak detection to drugs and food.
Main feature as follows:
1.High precision; High stability: able to detect any tiny and important leak
2.Easy to operate: PLC procedure from The central control room and the man-computer interface operation can store up set values of multiple and different types of products. Thus its easy to recall and switchover when detecting different products
3.nondestructive examination: Does not need the operator to explain
4.Has two kind of systems:the manual control system and the high speed on-line system
5.Enhance production efficiency; cut wastage;cost savings
6.The detection object include the empty bottle/pot and after filling bottle/pot
7.detectable sizes from 5 milliliters to 220 litres of plastic containers
8.High speed on-line leak detection: The PG quickest equipment may achieve 36,000 bottles/hour, are in the leading superiority in the world
9.Individuality design: All models can be custom-made according to the product characteristic and customer requirement
10.excellent cost performance.
PG push out leak detection equipments which include manual operation system and automatic on-line detection system according to the product characteristic and the customer specific requirement, Meanwhile researched and developed a series of automatic high speed rotating multi-stations on-line leak detection equipment for bottle and pot under the request of mass production from customers, thus satisfies the needs in the industries of food,drug and other canned industries.
