plastic bottle leak tester

PG plastic bottle leak tester introduction:

leak tester Adopting PLC control, enhance the flexibility of enlarging functions. Man-machine interface screen operating, simple and fast. Double-station testing together, promoting the productivity, reducing the waste, saving costs.

Testing speed: 2400-3000/hour
Conveyor belt 1500mm
Dimension (Lx W x H): size:1.5x0.7x1.7(m)
Electrical jack capacity: 2000mm-2800mm

Leak Tester feature:

1. High precision:High stability:able to detect any tiny and important leak
2. Easy to operate:PLC procedure from the central control room and the man-computer interface operation can store up set values of multiple and different types of products.Thus its easy to recall and switchover when detecting different products.
3. Nondestructive examinateion:Does not need the operator to explain
4. Has two kind of systems:the manual control system and the high speed online system
5. Enhance production efficiency ,cut wastage,cost saving
6. The detection object include the empty bottle/pot and after filling bottle/pot
7. Detectable sizes from 5milliliters to 220litres of plastic containers.
8. High speed online leak detection:The PG quickest equipment may achieve 36,000 bottles /hour
9. Individuality design:All models can be custom-made according to the product characteristic and customer requirement
10. Excellent cost performance

PG push out leak detection equipments which include manual operation system and automatic online detection system according to the product characteristic and the customer specific requirement,meanwhile researched and developed a series of automatic high speed rotating multi-stations online leak detection equipment for bottle and pot under the request of mass production from customers,thus satisfies the needs in the industries of food,drug and other canned industries.

Main

Advantages

Easy for Operation

Low energy consumption

Almost maintenance-free

Noise levels well below allowed limits

Reliability guaranteed above 99%

Alarm display

The leak testing machine is used for in-line Non-destructive container integrity testing.

Containers coming from the upstream section are automatically loaded onto the infeed and are routed towards the testing area.During the leak testing process testing group mobile toop parts are hermetically closed over the containers;the containers are then subjected to a suitable level of pressure.

Following leak testing process,the containers are automatically unloaded from testing area and they are managed according to result.

Technical specifications

Tested container   2pieces cans,3pieces cans,composite cans

Container filling   empty

Container content

Machine type     linear leak tester

Min container dimension 20*20*35mm

Max container dimension 20*320*500mm
