HOT! 3.5" car visual radar sensor with auto-dimming rear mirror for Toyota

Specifications

professional manufacturer; factory price
1.auto dimming
2.reverse camera
3.radar sensor for parking



 1. technical parameters



Operating Voltage	9.0 -16.0 Vdc
Operating Temperature	-40ºC ~ +85ºC
Storage Temperature	-40º C~ +100ºC
Maximum Current	<450 milliamps
High Reflectance	>70%
Low Reflectance	6~10%
Time to change reflectance from 55% to 15%	<6.0 seconds
Time to change reflectance from 15% to 55%	<8.0 seconds
N.W.	9KGS  (for 10pcs)
G.W.	10KGS(for 10pcs)



2.auto-dimming pinciple



According to the light intensity detected by the two sensors, it is automatically changed from the rearview or front reflectivity to the precise level necessary to optimize vision using advanced "Electrochromic" technology providing maximum glare management, so that it provides the most suitable reflectivity for drivers and avoid the traffic accident caused by the front or back car strong light intensity for the purpose that improve driving safety.



3.radar sensor



When drived backing cars, it will automatically show the distance with parking sensors and rearview image and are equipped with a bi-bi alarm by built-in buzzer;



4. reverse camera



When reverse gear is engaged,the system automatically switches from auto-diming to backup camera video,and when out-off reverse gear,it switches back automatically;



Our bracket is not clip on,when you buy,please tell us which bracket you need,or which type of your car,then we can make right mount for you.(detail see list below)







Details of mirror

1,bracket







  2,appearance









3,Spare Parts:









 4,Packing( neutral packing or follow client requirement )

(10pcs)
