Specifications
1)With ISO9001:2008 & ROHS certificate2)Fire-proof material
3)Widely use and competitive price
4)Energy saving material
Good quality industrial aluminum foil thick
Specifications
1. high Adhesion Strength
2. super Holding Power
3 good Conductivity
4. ISO 9001:2008 & ROHS certificated.
Main specification:
Ref.no |
Basic cloth |
Thickness of Alu. foil (micron)
|
Overall Thickness (mm)
|
Weight (g/m2)
|
Width (meter)
|
ALU-90 |
FG90 |
7/12/18/38 |
0.1 |
90 |
1/1.2 |
ALU-110 |
FG110 |
7/12/18/38 |
0.12 |
110 |
1/1.2 |
ALU-160 |
FG160 |
7/12/18/38 |
0.18 |
160 |
1 |
ALU-7628 |
FG7628 |
7/12/18/38 |
0.2 |
200 |
1/1.2/1.37 |
ALU-3732 |
FG3732 |
7/12/18/38 |
0.45 |
450 |
1/1.2 |
ALU-600 |
FW600 |
7/12/18/38 |
0.6 |
600 |
1 |
ALU-800 |
FW800 |
7/12/18/38 |
0.75 |
800 |
1 |
ALU-3784 |
FG3784 |
7/12/18/38 |
0.9 |
850 |
1 |
ALU-1000 |
FG1000 |
7/12/18/38 |
1 |
1000 |
1 |
1,temperature: 550 degree
2.width:1m,1.2m,1.5m or as your request
3.length:100m/roll ,200m/roll or as your request
4,Adhesive Type: Hydrogel/acrylate adhesive
5,MOQ:5000m2
Adhesive: high performance synthetic rubber-resin adhesive.
Liner: easy-release silicone release paper.
FEAUTURES:
-Aluminum backing provides excellent reflection of both heat and light.
-High quality adhesive with super strong adhesion and holding power offers reliable and durable
-Low moisture vapor transmission rate.
-Service Temperature range from -20 to +80ºC (-4 to +176ºF).fireproof material
TYPICAL APPLICATIONS:
1. Used as the export equipment packing materials for moisture barrier, water-proof, fire-retarding and anti-corrosion.
2. Processed to all kinds of fire-retarding products such as fire-proof packet, fire-proof suit, fire-proof bag, and fire-proof gloves etc.
3. Used as the thermal insulation material on Roof,wall,floor,tank,vessel,air conditioner,tank,heat supply pipes or construction materials for the purpose of fire-retarding, anti-corrosion, heat protection and sound aborption.
4. Packing chemical equipments such as oil and steam transportation pipeline.
PRODUCT FORM & SIZE AVAILABLE:
Roll Wide: 50mm/60mm/70mm/80mm/90mm/100mm/1.0m/1.2m or as customer request
Roll Length: 50m/100m/200m or as customer request
SURFACE PREPARATION:
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied must be clean, dry, free of grease, oil or other contaminants.
PRODUCT USE:
It is essential that the user evaluate the product to determine whether it is fit for a particular purpose and user's method of application. Good results will be obtained when applied to a clean, dry surface with a suitable pressure on product between +10 ~ +40ºC (+50 ~ +105ºF).
PRODUCT PHOTO:
ISO CERTIFICATIONS:
ROHS CERTIFICATIONS:
HIGH QUALITY MATERIAL:
PRODUCTION EQUIPMENT:
PACKAGE:
FACTORY OUTSIDE:
