Help CenterChina True Engin EPS-B Photoelectric Testing Switch
Related Products
-
Low Price China True Engin EPS-A High Quality Photoelectric Testing SensorNegotiableMOQ: 1 Unit -
China Manufacture 2015 New Model EPS-C Ultrasonic SensorNegotiableMOQ: 1 Unit
-
EPS-C Ultrasonic SensorNegotiableMOQ: 1 Unit
-
EPS-C China Manufacture Digital Fabric Printing Machine High Quality Ultrasonic SensorNegotiableMOQ: 1 Unit
-
EPS-C China Manufacture High Qualitylow Price Ultrasonic SensorNegotiableMOQ: 1 Unit
Wuhan True Engin Technology Development Co., Ltd is located in the coast of South Lake and surrounded by numerous universities.Company focuses on the researching and developing of industrial tension control system .Our company is committed to the tension control system early in China. After experienced a decade of prosperity , it has forged a excellent team in developing and researching .Our insititute possesses more than 20 professional engineers and CNC professors .They make technological innovation perseverely and guarantee highquality .Our company regards eminent service as the priori thing of development. We are committed to upgrading the tension control system in printing and packaging industry.Our target is roundly upgrading of machine control system home and abroad.
DETAILS
same axie catodioptric mode, single loop adjust,anti-pole protection,dampproof,it can be used with the EPC-100.
Specifications
mode |
light source |
outgoing line |
mode |
light source
|
outgoing line |
TR22 |
red |
four-core |
TR2 |
red |
three-core |
TG22 |
green |
four-core |
TG2 |
green |
three-core |
T22 |
red and green |
four-core |
T2 |
red and green |
three-core |
TB22 |
green and bule |
four-core |
TB2 |
green and bule |
three-core |
TW22 |
green and white |
four-core |
TW2 |
green and white |
three-core |
Parameters
test |
same axis reflect |
test distance |
10mm±2mm |
supply voltage |
DC10V-30V±10% corrugation<10% |
consume current |
<45mA |
| chromatography | red green blue white |
optic spot |
φ0.5~φ1.5 |
testing perspective |
light shall be verticalwith the objective deviation≤±15° |
response time |
0.0~1.0ms |
output style |
light , dark can be selected |
output indicator |
red LED |
output voltage |
high level≤1.5V low level≤1.2V |
load current |
≤200mA |
sensitivity |
single loop adjustment |
anti-ambient light |
incandescent light<3000Lx ambient light<1000Lx |
temperature |
operation-15℃~65℃ preservation-25℃~80℃ |
outgoing line |
φ5.4PVC |
protection |
Ip67(anti-damp and dust free) |
weight |
≈300g |
circuit protection |
voltage: Reverse Power Protection output:circuit protection |
||
current production |
current >200mA automatically shut down,<200mA automatically start
|
||
