SELON SEN-II MICROWAVE SYNTHESIS WORKSTATION

Wooden

Specifications

SELON SEN-II MICROWAVE  SYNTHESIS  WORKSTATION

microwave extraction  microwave digestion system  microwave extraction equipment

Introduction:

SEN-II is an enhanced microwave synthesis reaction workstation made for various reaction conditions. Unique patent pending two channel temperature monitor system is designed for large scale reaction states such as liquid, solid and liquid-solid mixture. Advanced microwave power auto-adjust function based on reaction temperature would generate non-pulse continuous microwave power for maximum microwave effect under specific reaction condition. Mechanical and Magnetic stirring devices are transferable, stirring speed is visible and adjustable. TFT color LCD screen is monitoring the whole process of reaction(Patented). The intake of inert gases has been equipped.

Technical Data:

Microwave power would be dynamically adjusted between 0 - 1000W based on reaction temperature. Maximum power has 10 ranges (increment 100W), microwave power would be auto-adjusted within each range.

Dual channel temperature monitor, theoretically maximum working temperature is 900 degree centigrade, vender suggested maximum temperature is 400 degree (need appropriate reaction case), standard configuration can support 250 degree, precision 1 degree.

Mechanical and Magnetic stirring devices are transferable, stirring speed is adjustable and would be displayed.

Standard interface reaction container (cubage from 20ml to 1000ml) and condensation, circumfluence devices, intake of inert gases.

Dual screen display for reaction data and accumulating temperature curve, TFT color LCD screen for monitoring and recording (through connecting to VCR) the whole reaction process (Patented).

Preset up to 30 reaction methods, there are more than 5 reaction variables changeable in each method, e.g. time, temperature, step, microwave power, stirring speed, etc.
